• Model NO.：TJ,4X8
• Transport Package：Container
• Specification：4500x2990x1850mm
• Trademark：METRO
• Origin：China, Shandong
• HS Code：8465990000
• Production Capacity：500sets,Year

Basic Info.

Model NO. TJ/4X8 Transport Package Container Specification 4500x2990x1850mm Trademark METRO Origin China, Shandong HS Code 8465990000 Production Capacity 500sets/Year

Product Description

Product Description

Heavy Model Glue Spreader For Plywood1.Main features:
1. Adopt the big diameter and high precision thick rollers: high rigidity, glue uniform.
2. Separately designed gears transmission box: Low noisy, work stable, long working life.
3. Start device specical designed for the rollers lifting and fasten: Safety, fast and convenient.
4. Roller speed and veneer out-put conveyor speed can be adjusted separately to meet different working requirements.
5. Emergency stop device to prevent any accidents.

2.Main technical specifications:

Glue sprader machine model	BTJ-8QZ
Rubber spreadering rollers	Φ418mm x 2pcs
Metal squeezing rollers	Φ295mm x 2pcs
Rubber spreading rollers speed	0-60rpm
Metal squeezing rollers speed	0-17rpm
Veneer out-put conveyor speed	0-90m/min
Glue spreader motor power	7.5Kw
Veneer out-put conveyor motor power	0.75Kw
Glue spreader machine overall dimension	4500x2950x1850mm
Glue spreader weight	5500Kgs

3. More Pictures:




4. Service:
Pre-sale
1.Free consultation about the equipment.
2.Reasonable purchasing plan and the production line designing plan are offered according to the clients' special requirment to help you to select the most suitable machinery.
3.Welcome to visit our factory and check our machine.
During-sales
1. We inspect and test the machine before delivery.
2.We are willing to freely tran your technicist and first-line operator.
After-sales
1.Engineers are available to service overseas.2.Videos about installing and debuging the equipment.


Welcome to Contact
