CNC Automatic Cutter 4 Axis /5 Axis Bridge Saw Stone Cutting Machine for Granite Marble Quartz Stone Slab Kitchen Countertop
Shandong Lintianzhiyuan CNC Equipment Co., Ltd.- Condition：New
- Certification：ISO, CE
- CNC or Not：CNC
- Voltage：220V
- Model：1325
- Working Area：1300(X)*2500(Y)*500(Z)mm
Base Info
- Model NO.：LT-1325
- Machine Structure：Cast Iron Vertical Shafts and Steel Gantry
- Table Surface：Aluminum T-Slot Table with PVC,Vacuum Table
- Spindle：Water Cooling Spindle,Air Cooling Spindle
- Spindle Rotating Speed：0-24000rpm,Min
- Guide Rail：Hiwin Linear Square Guide Rail
- Power：3.0kw,4.5kw,5.5kw
- Driving Method：X, Y by Helicia Gear Rack ;Z by Ball Screw
- Motors：Servo,Stepper Motor
- Drivers：Leadshine Drivers Ma860h
- Control System：Ncstudio,Mach3,DSP
- Invert：Fuling Invert
- Standard Software：Artcam2010
- Optional：Rotary Axis
- Transport Package：One Plywood Case
- Specification：3300*1950*1950mm
- Trademark：LINTCNC
- Origin：China
- HS Code：8465990000
- Production Capacity：400
Description
Application area
It is suitable for stone industry, stone stele processing industry, art relief, advertising industry, decoration industry and ceramic industry.
Applicable materials
1. Marble, granite, jade, bluestone, black stone, etc., as well as ceramics, glass, plexiglass, PVC board, aluminum-plastic board, bamboo and wood and other materials.
2. Hard stone such as granite can be carved in layers to 5mm
3. Marble, bluestone, etc. can be carved up to 5mm at a time
Service for CNC Router
1.Technical supports and suggestions before you order a machine according to your work piece.
2. Professional instruction for the operation of the machine.
3. 18 months warranty, we will provide the consumable parts at cost price after the warranty period. 4. Our
technician will come to your workshop if the problems can not be fixed through Internet or phone communications.
5. 24-hour technical support by email or calling.
FAQ
1) This is the first time I use this kind of machine, is it easy operate?
There are nglish manual or guide video that show how to use machine.
If there is still have any question, we can talk from phone or kype.
2)Can you recommend a CNC ROUTER MACHINE to me,thanks?
Yes, In order to give you a suitable router machine, ls tell me the max working
area, materialsfor processing and the thickness for materials processing engraving
or cutting. Then perfect suitable router will be recommended
3) If machine have any problem after I ordered it, how could I do?
Free parts send to you in machine warranty period if machine have any problem.
Free after-sales service life for machine, please feel free contact us if your machine
have any problem.we will give you 24hours service from phone and kype.
4) MOQ ?
Our MOQ is 1 set machine. We could send machine to your country port directly,
please tell us your port name. There will be best shipping freight and machine price
send to you
5)Payment terms
a. 30% by T/T in advance,70% by T/T before shipping.
b. L/C is acceptable ,if the amount is big,please issue the draft for our confirmation at first.
6)Delivery terms We will arrange the delivery as the terms we both agreed with after the confirmation by the buyer.
