4 Axis Big Rotary Woodworking CNC Router Machine 1325 Table with 2m Rotary for Pillar, Column, Figure, Sculptures

Linyi Chaoda International CNC Technology Co., Ltd.
  • Type：Engraving Router
  • Spindle Layout：Vertical
  • Spindle Number：Single-Spindle
  • Feed Mode：Mechanical
  • Controlling Mode：CNC
  • Certification：CE, ISO, BV, TUV

Base Info

  • Model NO.：JCF1325L
  • Customized：Customized
  • Condition：New
  • Color：Customized
  • Name：4 Axis Big Rotary Woodworking CNC Router Machine 1
  • Function：Produce 2D,3D Decoration Products,Big 3D Sculpture
  • Xyz Working Size：1300*2500*400mm(Customized)
  • Rotary Working Size：800mm Diameter, 2000mm Length(Customized)
  • Table Surface：Aluminium T-Slot with Clamps
  • Spinndle：4.5kw Air Cooling Spindle with Atc
  • Working Mode：Stepper Motor and Driver
  • Working Voltage：3 Phase AC380V ,220V
  • Operating System：4 Axis DSP Control System
  • Transport Package：Wooden Case Packages
  • Specification：working size diameter 800mm, length 2000mm
  • Trademark：CHAODA
  • Origin：China
  • HS Code：8464909000
  • Production Capacity：800sets,Year

Description

X,Y,Z,working area1300*2500*400mm(customized)rotary working size800mm diameter,2000mm length(customized)Lathe bed structureT-extrusion,Thick Steel frameTable surfaceAluminium T-slot with clampsX structureRack and pinion, linear square railY structureRack and pinion,  linear square railZ structureBall screw, linear square railReposition accuracy±0.03mmMax. rapid0-60000mm/minMax. working speed0-30000mm/minSpindle4.5kw air cooling with ATC FunctionSpindle speed0-24000RPMWorking modeBig power stepper motor and driverWorking voltage3 phase AC380V /220VCommand codeG code(*uoo,*nc,*mmg, *plt)Operating system4 axis DSP control system Running circumustanceTemperature: 0°C~45°C
relative humidity: 30%~75%4 Axis Big Rotary Woodworking CNC Router Machine 1325 Table with 2m Rotary for Pillar, Column, Figure, Sculptures
