Cabinet/Aliuminium MDF Embossment CNC Woodworking Machinery

Jinan Chanke Mechanical Equipment Co., Ltd.
  • Type:Engraving Router
  • Spindle Layout:Spindle Over
  • Spindle Number:Single-Spindle
  • Feed Mode:Mechanical
  • Controlling Mode:CNC
  • Certification:CE, ISO, FDA

Base Info

  • Model NO.:ck1325
  • Customized:Customized
  • Condition:New
  • Color:Customized
  • Working Size:1300X2500mm
  • Water Cooling Spindle Power:1.5,2.2kw,3kw,4.5kw,5.5kw,7.5kw
  • Working Table:Vaccum Pump or Materials Holders
  • Cooling Mode:Water Cooling Spindle or Air Cooling
  • Software:March 3 ,Nc Studio,DSP as Your Choice
  • Xy Structure:Xy with Helica Rack and Pinion
  • Z Structure:Tbi Ball Screw
  • Drive Motors:Leadshine Stepper Motor
  • Wood Machinery Square Rail:Taiwan Hiwin Square Rail
  • Inveter:Fuling or Delta Inverter
  • Transport Package:Plywood Packing
  • Specification:iso ,SGS,FDA,CE
  • Trademark:chanke
  • Origin:Shandong
  • HS Code:847989999
  • Production Capacity:50sets,Months

Description

Basic Info.

Model NO. ck1325 Customized Customized Condition New Color Customized Working Size 1300X2500mm Water Cooling Spindle Power 1.5/2.2kw/3kw/4.5kw/5.5kw/7.5kw Working Table Vaccum Pump or Materials Holders Cooling Mode Water Cooling Spindle or Air Cooling Software March 3 /Nc Studio/DSP as Your Choice Xy Structure Xy with Helica Rack and Pinion Z Structure Tbi Ball Screw Drive Motors Leadshine Stepper Motor Wood Machinery Square Rail Taiwan Hiwin Square Rail Inveter Fuling or Delta Inverter Transport Package Plywood Packing Specification iso /SGS/FDA/CE Trademark chanke Origin Shandong HS Code 847989999 Production Capacity 50sets/Months

Product Description


This is one type of woodworking machinery of Jinan chanke mechnical Equipment Co.,LTD . this woodworking machinerymachine working size is: 1300x2500x200mm, aluminium profile table, has the Tsolt, using the material holders to fasten the mould on the table. It can working on the MDF, wood to make the cabinet door, soild wooden door, computerdesk, assembling desk , it also can engrave on the HDF,wood board, acrylic ,plan cutting, 3D embossment
we use  the Chinese water cooling spindle, we aslo have the HSD air cooling spindle. as your choice. XY gear transmission, Z Taiwan ball screw transmission. Weihong NK105 DSP control system, leadshine stepper motor, or Servo motor driving system, Fuling inverter.

we have vacuum table wood cnc router, 8 pieces of head wood cnc router, ATC cnc router.. All kinds of machines are one goal is to service and convenience for the users.

So welcome to contact us when you need wood working machines on the wooden , MDF doors or the furniture..

Forget to tell you, we can according to your requipments to produce the wood cnc router machine, like the working size, the colour of this machine, using which size of driving motor.... so don't hesitate contact us !


It can cut and engrave on the wood MDF and other materials to do the 3D embossment work , furniture and Crafts.   can aslo engrave on the acrylic, alumnium brass copper ...

  Technical data :

Brand

chanke

Model
woodworking machinery

Machine Size
(mm)(W*L*thickness)

1900*3100*1800

Table size(mm)

1600*3100

Engraving area
(W*L*thickness)(mm)


1300*2500*200

Working Form

Full-automatic

Spindle Power

3.0KW water cooling spindle

Spindle Rotate(rpm)

6000~24000

Motor Driver

Stepper motor (Chinese servo motor or imported servo motor is optional)

Tool Diameter(mm)

Ø3.175,Ø4,Ø6, Ø12.7mm

Machine Structure

Industry square tube structure

Transmission System

Imported ball screw or high accuracy gear rack

X,Y,Z Rail

Imported square rail

Mechanical Accuracy

<0.03/300mm

Engraving Speed(mm/min)

8000~12000mm/min

Feeding Speed

manual

Data Transmission

PC connect

Support Format

G code or HPGL

Working Voltage

AC220V/50Hz or 380V/50Hz

Support Format

G Code or HPGL

Range of Application

Woodworking relief engrave ,Cutting , Hollow

Machine Net Weight

1500Kg



All woodworking machine are packed with standard inner plastic wrap and steel structure and outer plywood case, inner package would be help to tight all the Small parts in the package. and the plywood is firm enough to protect the laser machine during shipping.

The advantages of plywood case package:

Firstly, plywood case, its compressive strength and bearing quality is better, is the market of choice for the goods of high weight packing.

Secondly, the board area is big, the soil structuer is good and operational process is simple, so its is better in leakproof ness and waterproof.

Thirdly, when importing, the plywood case is with fumigation-free, the produre is simple.

Guarantee & After Sales Service:

1. 2 years quality guaranty, the machine with main parts (excluding the consumables) shall be changed free of charge when problems happened during the warranty period.
2. Lifetime maintenance free of charge.
3. Free training course at our plant.
4. We will provide the consumable parts at an agency price when you need replacement.
5.12 hours on line service each day, free technical support.
