• Model NO.：SR13A
• Condition：New
• Color：Iron Grey
• Working Width：40-1300mm
• Working Thickness：3-110mm
• Feed Speed：10-70m,Min
• Net Weight：6500kgs
• Overall Dimension(Lxwxh)：2120X2980X2440mm
• Transport Package：Standard Plastic Film
• Trademark：Metro
• Origin：Shandong, China
• HS Code：8465930000
• Production Capacity：50set,Month

Basic Info.

Model NO. SR13A Condition New Color Iron Grey Working Width 40-1300mm Working Thickness 3-110mm Feed Speed 10-70m/Min Net Weight 6500kgs Overall Dimension(Lxwxh) 2120X2980X2440mm Transport Package Standard Plastic Film Trademark Metro Origin Shandong, China HS Code 8465930000 Production Capacity 50set/Month

Product Description

Single side calibrating sander machine
1.Incorporating advanced technology ,using high quality imported parts and accessories and featuring stable performance ,precision double-side processing with thickness tolerance of± 0.1mm.
2.The machine is structured by cold forming rectangle steel,noted for high rigidity,vibration damping and deformation free.
3.Easily operated inverter speed regulator for reliable meterial feeding.
4.Simplified operation of the computer terminal with the industrial-grade touch screen.

Main technical specifications:

Model	SR13A
Working width	40-1300mm
Working thickness	3-110mm
Working length	≥750mm
Abrasive belt speed	20m/s
Feed speed	10-70m/min
Size of abrasive belt (WxP)	1330x2615mm
Total motor power	64Kw
Main motor	55Kw
Working air pressure	0.55Mpa
Consumption of compressed air	0.1m3/min
Volume of sucked air	10000m3/h
Speed of sucked air	25-30m/s
Overall dimension (LxWxH)	2120x2980x2440mm
Net weight	6500Kgs

Machinery parts list:
1. One set of SR13A Sander.
2. One set of vacuum table perforated conveyor belt.
3. One set of fan blower.
