High Speed Hot Sale Wood Veneer Spindle Less Rotary Peeling Machine for Making Plywood
Linyi Sin San Lin Smart Machinery Co., Ltd.- Type：Veneer Peeling Machine
- Automatic：Automatic
- Certification：CE, ISO, FDA
- Color：Grey
- Voltage：380,415V
- Peeling Speed：60-120m,Min
Base Info
- Model NO.：MHF1400
- Control：PLC Control
- Customized：Customized
- Transport Package：Container
- Specification：4ft peeling machine
- Trademark：METROMACH
- Origin：China
- HS Code：846596000
- Production Capacity：100set,Month
Description
Basic Info.
Model NO. MHF1400 Control PLC Control Customized Customized Transport Package Container Specification 4ft peeling machine Trademark METROMACH Origin China HS Code 846596000 Production Capacity 100set/MonthProduct Description
High Speed 4FT Wood Veneer Peeling MachineSpindleless veneer peeling machine is used for make veneer .And it is suitable for the eucalyptus, pine, cotton wood and another log.
The quality of the veneer determines the quality of the plywood, so controlling the quality of the veneer is the premise and the most important part of producing standard plywood.
veneer peeling machine is a very technical equipment in plywood line equipment.Technical parameters:
| Max. working length | 1400mm |
| Working diameter range | 22~500mm |
| Max. woring speed | 90m/min |
| Veneer thickness | 0.5~7mm |
| Double rollers motor power | 7.5kw x 2sets |
| Single roller motor power | 5.5kw x 2sets |
| Screw Feeding motor power | 11kw |
| Rotary clipper motor power | 1.5kw |
| Rubber belt conveyor motor | 1.5kw |
| Machine size | 4700x1900x1500mm |
| Machine weight | 7000kgs |
| Total power | 40kw |
