• Model NO.：E300
• Control Method：Open-Loop Control
• Numerical Control：CNC,Mnc
• Processing Precision：0.01~0.02(mm)
• Performance Classification：High-End CNC Machine Tools
• Application：Wood,Stone,Mable,Tile,Granite,Tombstone,Sign Plate
• Transport Package：Wooden Case Package
• Specification：1230*2440*50mm
• Trademark：Mars
• Origin：China
• HS Code：8465990000
• Production Capacity：300 Sets,Month

Basic Info.

Model NO. E300 Control Method Open-Loop Control Numerical Control CNC/Mnc Processing Precision 0.01~0.02(mm) Performance Classification High-End CNC Machine Tools Application Wood/Stone/Mable/Tile/Granite/Tombstone/Sign Plate Transport Package Wooden Case Package Specification 1230*2440*50mm Trademark Mars Origin China HS Code 8465990000 Production Capacity 300 Sets/Month

Product Description

CNC Panel Furniture Production Line-Routing, Cutting, Side Milling, Sawing, Chamfering, Milling, Drillng Machine
Keywords:15 years experience of production
                     ISO9001:2008, CE, SGS, AAA Level Enterprise which Honors Contract
                    Three Brand: Mars, Golden Eagle,Borio

Description:
CNC Panel Furniture Production Line-Routing, Cutting, Side Milling, Sawing, Chamfering, Milling, Drillng Machine is MARS featured machine for processing molded doors, wooden windows, wooden cabinet, wood panels. MARS design it for many years, now popular in the market, it's economic machining center of woodworking cutting machine.

Functions:
The functions of this machine include milling on artificial stone,wood,bamboo,etc.,processing of various patterns and characters.

Applicable Materials:
Artificial stone,wood,bamboo,marble,organic board,two-color board,etc..


Application Scope:
Cabinet doors,wooden doors,solid wood,panels,doors&windows,tables&chairs,screens,wave panels,large wall hangings,advertising panels,logo&sign making.



Parameters:

Model	E300 Gang Drill CNC Cutting Center
Working Stoke	1230*2440*50mm
Body Structure	Heavy-duty thicken steel structure, w/ tempering
Spindle Power	HQD 6KW+4.5KW air cooling spindle
Spindle Speed	0 ~ 24000 rpm/min
Drilling Bank	Italy HSD 5+4 gang drill
Control System	Syntec/ Osai
Drive System	Yaskawa/ Delta servo motor
Lubrication System	Automatic
Transmission	XY axis rack and pinion, Z axis ball screw
Guide Rail	Taiwan Hiwin rectangular linear rail
Vacuum Pump	5.5KW
Max Travelling Speed	50m/min
Max Processing Speed	30m/min
Dictate Format	G code/ HPGL
Working Accuracy	±0.02mm
Re-positioning Accuracy	±0.05mm
Support Software	Professional cutting optimization software
Working Voltage	AC380/ 3PH/ 50HZ
Net Weight	3000KG
Machine Size	3700*3100*1900mm

Accessories:

Performance Features:

1. Equipped with all the leading international brand components.
2. High-power Italy HSD air-cooling spindle, Japan YASKAWA servo motor and driver.
3. Vacuum table, high adsorption capacity, able to adsorb materials of different sizes.

4. Intelligent protection work table can prevent table damages caused by misuse or software errors. Intelligent processing cross-border protection can prevent mechanical collisions while design layout exceeds processing area.
5. Syntec CNC control system can automatically accomplish multi-layer 3D job, cutting, engraving, milling, all at ease. Offline operation can be realized.

Samples:
