• Model NO.：ZD400T
• Certification：CE, ISO
• Customized：Customized
• Condition：New
• Color：Customized
• Transport Package：Wood Box
• Specification：3250*3150*900 mm
• Trademark：Qingdaozhongding
• Origin：Qingdao
• HS Code：84659100
• Production Capacity：500 Sets a Year

Basic Info.

Model NO. ZD400T Certification CE, ISO Customized Customized Condition New Color Customized Transport Package Wood Box Specification 3250*3150*900 mm Trademark Qingdaozhongding Origin Qingdao HS Code 84659100 Production Capacity 500 Sets a Year

Product Description

Feature:

1.Apply to processing all kinds of density boards, shaving boards, artificial board, ABS board, PVC board, organic glass plates and solid wood and others with wood structure and similar hardness.
2.Moveable table guide track is chromium steel bar structure, exact and durable
The sliding table is made of high strength extruded aluminum alloy, and it is high in strength and won't bent
3.With oxidation treatment, the sliding table surface is beautiful and durable
4.The body is welded with heavy-duty steel and with special heat treatment, better stability and lower noise
5.The saw blade lifting is electrical controlled with titling digital display to make the operation more precision simple

 Technical Data:


Type	ZD400T
Dimension of sliding table	3200x415 mm
Gross cut capacity	3200 mm
Width of cut between saw blade and rip fence	1250 mm
Tilting saw group	0-45°
Diameter of main saw blade	400 mm
Max cutting height (90°)	125 mm
Speed of main saw spindle	3000/4000/5000 r.p.m
Main saw motor power	5.5 kw
Main spindle diameter	30 mm
Diameter of scoring saw blade	120 mm
Speed of scoring saw spindle	8000 r.p.m
Scoring saw motor power	1.1 kw
Scoring saw spindle diameter	22 mm
Lifting of saw blade	Electrical lifting
Cutting degree readout	Digital readout
Weight	1100 KGS
Overall dimension	3250x3150x900 mm


product deteils;









Other information:

1) Term of payment: T/T, 30% deposit and the balance is paid before delivery
2) Delivery: 25days
3) Machine voltage: optional
4) Warranty: 1 year
5) MOQ: 1 Set
6) OEM service is ok
7) HS code: 84659100
8) Certificate: CE&ISO 9000 Certificate
