Dining Chair Sanding Production Lines
Qingdao Samac International Trading Co., Ltd.- Type：Belt Wood Sander
- Automatic Grade：Automatic
- Variable Speed：Without Variable Speed
- Certification：ISO
- Customized：Customized
- Condition：New
Base Info
- Model NO.：sander
- Color：Customized
- Transport Package：Plastic Film
- Specification：sanding line
- Trademark：SAMACH
- Origin：China
- Production Capacity：80sets,Month
Description
Tianyang Motor Hengxing reduction gearsInfeed Speed 6-15m/min Min Working Length 380mm Max Working Width 80mm Max Working Height 80mm Infeed Wheel Diameter 100mmTaiwan Meina Pneumatic Components Taiwan Airtac VFD SHIHLIN Spindle Bearing NSK Buttons Contactors LG APT famous brand Sanding Belt Length 1520X150mm Connection type Butt joint Dust Collect Pipe Diameter 100mm 2pcs
This machine is mainly aimed at the grinding and processing equipment of the back feet of the dining chair. The fuselage is made of sheet metal forming and welding, with good structure and small deformation. Each processing position is processed by precision processing. With the humanized setting of clamping feeding device, the relative position of grinding frame and feeding wheel can be adjusted on one side of the production line; the middle position of clamping feeding device can be controlled by pneumatic control and electrical control, which is convenient, convenient and highly plasticity. The abrasive belt is variable frequency speed regulation, which meets the needs of different environments.
MSQ370 Curved surface chamfering machine
This machine is mainly for grinding the edges of front and rear feet of dining chairs. The fuselage is made of sheet metal forming and welding, with good structure and small deformation. Each processing position is processed by precision processing. Humanized clamping feeding device can adjust the relative position of grinding frame and feeding wheel on one side of the production line; convenient and high plasticity!
MSP330Z Double Vertical Polishing Sander
This machine is mainly aimed at polishing the front and rear feet of the dining chair on two vertical planes. The fuselage is made of sheet metal forming and welding, with good structure and small deformation. Each processing position is processed by precision processing. With the humanized setting of clamping feeding device, the relative position of grinding frame and feeding wheel can be adjusted on one side of the production line; the middle position of clamping feeding device can be controlled by pneumatic control and electrical control, which is convenient, convenient and highly plasticity.
MSP330L Double Flat Surface Polishing Sander
This machine is mainly used for polishing the front and rear feet of the dining chair. The fuselage is made of sheet metal forming and welding, with good structure and small deformation. Each processing position is processed by precision processing. Humanized clamping feeding device can adjust the relative position of grinding frame and feeding wheel on one side of the production line; convenient and high plasticity!
This machine is mainly aimed at the grinding and processing equipment of the back feet of the dining chair. The fuselage is made of sheet metal forming and welding, with good structure and small deformation. Each processing position is processed by precision processing. With the humanized setting of clamping feeding device, the relative position of grinding frame and feeding wheel can be adjusted on one side of the production line; the middle position of clamping feeding device can be controlled by pneumatic control and electrical control, which is convenient, convenient and highly plasticity. The abrasive belt is variable frequency speed regulation, which meets the needs of different environments.
MSQ370 Curved surface chamfering machine
| Spindle Power | 3 KW 1pc |
| Infeed Motor Power | 0.18KW |
| Infeed Speed | 6-15m/min |
| Min working Length | 370mm |
| Max working Width | 80mm |
| Max Working Height | 80mm |
| Infeed Wheel Diameter | 100mm Taiwan Meina |
| VFD | SHIHLIN |
| Spindle Bearing: | NSK |
| Buttons Contact | LG APT famous brand |
| Sanding Belt Length | 1240X65mm |
| Connection type | Butt joint |
| Dust Collect Pipe Diameter | 100mm 1pc |
This machine is mainly for grinding the edges of front and rear feet of dining chairs. The fuselage is made of sheet metal forming and welding, with good structure and small deformation. Each processing position is processed by precision processing. Humanized clamping feeding device can adjust the relative position of grinding frame and feeding wheel on one side of the production line; convenient and high plasticity!
MSP330Z Double Vertical Polishing Sander
| Spindle Power | 1.5 KW 2pc |
| Infeed Motor Power | 0.18KW 4pcs |
| Infeed Speed | 6-15m/min |
| Min working Length | 330mm |
| Max working Width | 80mm |
| Max Working Height | 80mm |
| Infeed Wheel Diameter | 200mmTaiwan Meina |
| VFD | SHIHLIN |
| Spindle Bearing: | NSK |
| Buttons Contact | LG APT famous brand |
| Connection type | Butt joint |
| Dust Collect Pipe Diameter | 100mm 2pc |
This machine is mainly aimed at polishing the front and rear feet of the dining chair on two vertical planes. The fuselage is made of sheet metal forming and welding, with good structure and small deformation. Each processing position is processed by precision processing. With the humanized setting of clamping feeding device, the relative position of grinding frame and feeding wheel can be adjusted on one side of the production line; the middle position of clamping feeding device can be controlled by pneumatic control and electrical control, which is convenient, convenient and highly plasticity.
MSP330L Double Flat Surface Polishing Sander
| Spindle Power | 1.5 KW 2pc |
| Infeed Motor Power | 0.18KW 4pcs |
| Infeed Speed | 6-15m/min |
| Min working Length | 330mm |
| Max working Width | 80mm |
| Max Working Height | 80mm |
| Infeed Wheel Diameter | 200mm Taiwan Meina |
| VFD | SHIHLIN |
| Spindle Bearing: | NSK |
| Buttons Contact | LG APT famous brand |
| Connection type | Butt joint |
| Dust Collect Pipe Diameter | 100mm 2pc |
This machine is mainly used for polishing the front and rear feet of the dining chair. The fuselage is made of sheet metal forming and welding, with good structure and small deformation. Each processing position is processed by precision processing. Humanized clamping feeding device can adjust the relative position of grinding frame and feeding wheel on one side of the production line; convenient and high plasticity!
