• Model NO.：ZSF-80DL
• Panel Thinkness：9-60mm
• Min.length panel：150mm
• Min.width panel：60mm
• Manufacturing Principles：Glue Tank Overhead
• Customized：Non-Customized
• Transport Package：Plywood Boxes
• Specification：8200*760*1600mm
• Trademark：Mars
• Origin：China
• HS Code：84659900
• Production Capacity：300sets Per Month

Basic Info.

Model NO. ZSF-80DL Panel Thinkness 9-60mm Min.length panel 150mm Min.width panel 60mm Manufacturing Principles Glue Tank Overhead Customized Non-Customized Transport Package Plywood Boxes Specification 8200*760*1600mm Trademark Mars Origin China HS Code 84659900 Production Capacity 300sets Per Month

Product Description

ZSF-80DL Automatic Wood Edge Banding Machine

1,Technical Parameter

Overall dimensions(L*w*H mm)	8200*760*1600mm
Motor power	16.5kw Total power
Feed speed	17-25m/min
Edge thickness	0.4-3mm
Panel thickness	9-60mm
Panel Length	>=150
Panel Width	>=60
Working press	0.7Mpa
Mini Panel Size	300(L)*60(W) mm & 150(L)*150(W)mm
Total weight	2450KGS

2,Applicable Scope

Processing	Pre-milling, gluing, edge cutting, end trimming, rough trimming, fine rimming, corner trimming, scr aping, buffing, slotting and so on
Material	MDF, block board, solid wood board, particleboard, polymer door plates, plywood etc, straight line e dging and trimming
Application	It is especially suitable for large and medium-sized furniture manufacturers
Strength	Flexible, advantages of high performance, easy debugging, convenient in maintenance and easy to operate

3,Performance Feature

1	This edge bander is ideal for building an automatic production line. Stability and controlled ability ar e the most important factors for an equipment to be part of production line
2	Pre-milling equipment with double trim-blades works on the waved effect that is caused by precise saw
3	The glue mechanism adopts a special structure to gelatinize the plates and coating materials uniform ly, ensure a more solid conglutination
4	End-trimming mechanism through a precise guide track movement, adopt automatic tracking and hi gh-frequency motor fast cutting structure to ensure the cutting surface smoothly
5	Rough &Fine Trimming unit, with two individual high frequency motors, trim the exceeding edge on t he top and bottom side of the panel, ensure the top and bottom side of the edge smooth and even
6	Scraping unit for a perfect finishing of the applied edge
7	The buffing device adopt the board processed by cotton polishing wheel, by end-polishing to mak e a more smooth surface
8	Grooving is a optional function for edge banding machine. It's used to slot out one groove on panel to install glass, back panel etc

4,Warranty Information

Warranty and Service:

Guarantee:12 months for the whole machine. Within 12 months under normal use and maintenance, if something is wrong with machine, you will get spare part for free. Out of 12 months, you will get spare part at cost price. Technical support: You will also get technical support and service all the lifetime. Technical support by phone, email or Whatsapp/Skype around the clock Friendly manual and operation video online Engineer available to service machinery oversea



After sales Services	Normal machine is properly adjusted before dispatch. You will be able to use the machines immediately. You will be able to get free training advice towards our machine in our factory. You will also get free suggestion and consultation, technical support and service by email/fax/tel and lifetime technical support.
Quality control	Skilled and Strict Quality Inspection Team is available during the material purchasing and production procedure according to ISO 9001:2015 All finished machine we shipped out are 100% strictly tested by our QC department and engineering department
