Woodworking Core Veneer Roller Dryer Machinery
Linyi Sin San Lin Smart Machinery Co., Ltd.- Certification：CE, ISO, FDA
- Woking Width：2800mm
- Working Decks：3decks
- Length of Heating Section：2000mm X 8 Sections
- Length of Cooling Section：2000mm X 1 Section
- Machine Oveall Dimension：23000X5200X4010mm
Base Info
- Model NO.：BG1333-I
- Machine Net Weight：68000kgs
- Heating Medium：Thermal Oil or Hot Steam
- Heat Source：Boiler
- Transport Package：Container
- Specification：2300x5200x4100mm
- Trademark：METRO
- Origin：China
- HS Code：8419320000
- Production Capacity：50set,Month
Description
Basic Info.
Model NO. BG1333-I Machine Net Weight 68000kgs Heating Medium Thermal Oil or Hot Steam Heat Source Boiler Transport Package Container Specification 2300x5200x4100mm Trademark METRO Origin China HS Code 8419320000 Production Capacity 50set/MonthProduct Description
Woodworking Core Veneer Roller Dryer MachineryMain features:
This series of roller dryer is one of the main machines in plywood production line. It is very suitable for wet clipping processing and drying thick veneer.
Advantage:New technology and advanced PLC controlling system have been used for effective and quality drying veneers with lower energy consumption.
The BG1333 roller dryer machine is 13 sections as a standard, 2 meters as a standard for one heating section, one cooling section, one conveying system, one input roller table, and one output roller table. Customers can use the machine from 8 sections to 18 sections that it is up to your needs.
Technical specifications:
| Machine model | BG1333-I |
| Density | 550Kg/m3 |
| Veneer thickness range | 1.5-3.6mm |
| Initial moisture content | 80% |
| Final moisture content | 10% |
| Load ratio | 80% to 85% |
| Woking width | 2800mm |
| Working decks | 3decks |
| Length of heating section | 2000mm x 8 sections |
| Length of cooling section | 2000mm x 1 section |
| Transmission speed | 0-15m per min |
| Drying capacity | 3-4m3 per hour |
| Steam consumption | 2100kg per hour |
| Installation motor power | 117.5kw |
| Transmission motor power | 7.5Kw x 3sets |
| Ventilation motor power | 11Kw x 8sets |
| Cooling motor power | 7kw |
| Machine oveall dimension | 23000x5200x4010mm |
| Machine net weight | 68000Kgs |
Packing&Shipping:
1. Machine body packed in plastic film
2. Spare parts and electrical parts packed in plywood boxes.
3. Fixed in container with steel wires.
Our Services:
1. Design and produce based upon your production need. Provide full sets of drawings and manuals.
2. One year warranty for the machine. Liftetime after-sales service and maintenance.
3. Professional team for oversea machine installation&debugging.
4. Help train and guide machine operating.
