6090 Wood, Stone, Jade, Rubber, Soft Metal CNC Carving Machine, CNC Router Machine

Jinan Guanjiahong CNC Machinery Co., Ltd.
  • Warranty：1 Year
  • Type：Engraving Router
  • Spindle Layout：Spindle Over
  • Spindle Number：Single-Spindle
  • Feed Mode：Mechanical
  • Controlling Mode：CNC

Base Info

  • Model NO.：6090
  • Certification：CE, ISO
  • Customized：Customized
  • Condition：New
  • Color：Customized
  • After-sales Service：Lifetime
  • Drive Mode：Stepper
  • Guild Rail：Hiwin Square Rail
  • Ball Screw：PMI
  • Control System：Nc Studio
  • Transport Package：Standard Exported Plywood Case
  • Specification：CE
  • Trademark：DONGTONG
  • Origin：Shandong China
  • HS Code：84609090
  • Production Capacity：300 Sets Per Month

Description

NO Performance Performance Parameter1 Working area X axis600mm   Y axis900mm   Z axis120mm3 Accuracy Working accuracy0.02mm   Repostioning accuracy0.02mm4 Drive mode X axisBall screws   Y axisBall screws   Z axisBall screws5 Speed Max travel speed8000mm/min   Max working speed6000mm/min6Spindle(water-cooling) Spindle power2.2KW   Spindle speed0-24000r/min7 Running mode Stepper 8 Working voltage AC220V/50HZ9 Command code G code10 Operating system NC STUDIO12 Guild rail Square rail13 Gantry  Cast aluminum14 Table  Aluminum alloy  Tslot15 Total machine power 2300W16 Machine size 1400×1100×1650mm12 Machine weight 350 KGS
6090 Wood, Stone, Jade, Rubber, Soft Metal CNC Carving Machine, CNC Router Machine6090 Wood, Stone, Jade, Rubber, Soft Metal CNC Carving Machine, CNC Router Machine


6090 Wood, Stone, Jade, Rubber, Soft Metal CNC Carving Machine, CNC Router Machine



6090 Wood, Stone, Jade, Rubber, Soft Metal CNC Carving Machine, CNC Router Machine
6090 Wood, Stone, Jade, Rubber, Soft Metal CNC Carving Machine, CNC Router Machine
If you have specific requirement of 6090 wood stone CNC router, please contact with us.
Customization is available.
