• Model NO.：DW-1325
• Cylinderical Wood Engraving Area：Diameter: Max300mm Length Can Be Customized
• X,Y,Z Traveling Positioning Accuracy：±0.05,300mm
• Table Surface：T-Slot Table
• Frame：Welded Strucutre
• X,Y Structure：Rack and Pinion Drive, Hiwin Rail Linear Bearings
• Z Structure：Ball Screw, Hiwin Rail Linear Bearings
• Driver Motor：Stepper Driver
• Type：Engraving Router
• Spindle Layout：Vertical
• Spindle Number：Double-Spindle
• Feed Mode：Manual
• Controlling Mode：CNC
• Customized：Customized
• Color：Customized
• Transport Package：Plywood Box, Free From Fumigation
• Specification：CE FDA
• Trademark：dwin made in china
• Origin：Jinan, Shandong, China
• HS Code：8465990000
• Production Capacity：50sets Per Month

XY working area
1300x2500 x  Φ 200mm
Z working area
200mm
Table size
2100mm*3100mm*1750mm
Max feeding
4m-5.5m/min
Work-holding
2m-3m/min
 Resolution
0.005mm
Interface
USB
Command
G code*.u00*.mmg*.plt
Surroundings for software
Windows98/2000/xp
Power(not include the spindle)
500W
Working voltage
AC220V/50Hz
spindle power rate
2.2KW water cooling
spindle rotating speed
0-24000rpm/min
Drive motor
stepper



Parts of the machine can do some changes as your requirement:
1. Motor (stepper or sever motor)
2. Spindle ( air-cooling or water-cooling spindle)
3. Guide rail (round guide rail or square guide rail)
4. The table of the machine (Vacuum table, T-slot table, Combination of Vacuum table & T-slot table, normal table, table moving)

Standard accessories
DSP handle, Cable, Water cooling system, Power cable, Clamp, Wrench, Bit, Collet, Other tools

Company Advantages
1, First-class factory meets international production plant's standard, ten years' manufacture and export experiences
2, Own most advanced domestic cnc machining production equipments
3, 5-9 days machine production time, one year warranty and lifetime free maintenance
4, OEM and ODM services available
5, Same quality, our price and service are better; Same price, our quality and service are better
6, with CE, FDA, SGS, ISO9000 certifications
