• Model NO.：JCT1325L
• Flat Working Size：1300mm X 2500mm X 400mm
• Table：Removable Flat Table
• Spindle：4.5kw Air Cooling Spindle
• Motor and Driver：Stepper Motor and Driver
• Control System：4 Axis DSP
• Inverter：Fuling
• Transport Package：Wrapped with Protection Film,Fasten by Metal Wires
• Specification：3700*2400*2300mm
• Trademark：CHAODA
• Origin：China

Model No.JCT1325L Flat working size1300*2500*400mmRotary working size800mm diameter, 2000mm lengthLathe bed structureT-extrusion, Thick Steel frameTable Removable, T-slot with clampsX structure  Rack and pinion, linear square railY structureRack and pinion, linear square railZ structure Ball screw, linear square railReposition accuracy±0.02mmMax. travelling speed 0-55000mm/minMax. working speed0-25000mm/minSpindle4.5kw air cooling spindleDriving systemLarge power stepper motor and driverOperating system4 axis DSPOperation languageG codeWorking voltageAC220V or 380V, 3-phase, 50HzWorking materialsEps foam, Styrofoam, Woods, MDF, Composite boards, Alucobond, PVC, Rigid plastics, Polyester, Fiberglass, Acrylic, Organic glass, Aluminum, etc.





1. Sample testing before shipment
2. Provide 2 days free training for each machine
3. 12 months warranty for each machine
4. Friendly English version manual and operation videos for studying
5. Free technical support by phone,email,chatting or remote
6. Engineers available to service machinery overseas
