• Model NO.：JCW1325
• Certification：CE, ISO, BV, TUV
• Customized：Customized
• Condition：New
• Color：Customized
• After-sales Service：Life Time Technical Support
• X,Y,Z Working Area：1300*2500*200mm(Customized)
• X,Y,Z Structure：Taiwan Hiwin Square Linear Guide Rail
• X,Y Structure：Rack and Pinion Transmission
• Z Structure：Imported Ball Screw, High Precision
• Spindle：4.5kw Water Cooling
• Driving System：Stepper Motor and Driver (Optional:Servo Motor)
• Operating System：3 Axis DSP Controller
• Software：Artcam or Type 3
• Transport Package：Wooden Case Package
• Specification：working size 1300*2500*200mm(custolized)
• Trademark：CHAODA
• Origin：China
• HS Code：8464909000
• Production Capacity：5000sets,Year

X,Y,Z,working area1300*2500*200mm(SIZE CAN BE CUSTOMIZED)Lathe bed structureThick steel frame,heavy dutyTable surfaceVaccum table or Clamp tableX structureRack and pinion,Taiwan HIWIN linear square railY structureRack and pinion, Taiwan HIWIN linear square rail,Y double motor driveZ structureBall screw, Taiwan HIWIN linear square railResolution±0.02mmReposition accuracy±0.05mmMax.operating speed0-30000mm/minMax.working speed0-20000mm/minSpindle power 4.5kw water cooling spindle (optional: air cooling)Spindle speed0-24000RPMWorking modeStepper motor and driver (optional:servo motor and driver)Command codeG code(*uoo,*nc,*mmg, *plt)Operating system3 axis DSP controllerSoftwareArtcam/Type 3Working voltage220v/380v(others available)Running circumstanceTemperature: 0°C~45°C relative humidity: 30%~75%Net weight1200kgSpare Parts1 Software CD,1 Education CD,1 Data cable,1 Power cable,12Tools,2 Wrenches,1 Dust collectorPackingstandard wooden caseDelivery Time30daysPayment Terms50% T/T start production,50% T/T balance before shipmentWarrantyMain parts free change for one year,offer lifetime online and phone servicesOptional DevicesMulti-spindle,0-180 degree rotary spindle,Rotary axis,Software,3D scanner and other configurationsSample Pictures:
