• Model NO.：HBQS1815,450HK
• Knife Size：1500mm
• Veneer Thickness：0.5-7mm
• Color：Customized
• Control：PLC Control
• Transport Package：Container
• Specification：4FT Peeling Machine
• Trademark：METROMACH
• Origin：Shandong, China
• HS Code：846596000
• Production Capacity：100set,Month

Basic Info.

Model NO. HBQS1815/450HK Knife Size 1500mm Veneer Thickness 0.5-7mm Color Customized Control PLC Control Transport Package Container Specification 4FT Peeling Machine Trademark METROMACH Origin Shandong, China HS Code 846596000 Production Capacity 100set/Month

Product Description

PRODUCT DESCRIPTIONHigh Speed 4FT Wood Veneer Peeling Machine1. Fearures
Spindleless veneer peeling machine is used for make veneer .
And it is suitable for the eucalyptus, pine, cotton wood and another log.
The quality of the veneer determines the quality of the plywood, so controlling the quality of the veneer is the premise and the most important part of producing standard plywood.
veneer peeling machine is a very technical equipment in plywood line equipment.

2. Technical Parameters

Max. working length	1400mm
Working diameter range	22~500mm
Max. working speed	90-120m/min
Veneer thickness	0.5~7mm
Double rollers motor power	7.5kw x 2sets
Single roller motor power	7.5kw x 2sets
Screw Feeding motor power	11kw
Rotary clipper motor power	2.2kw
Rubber belt conveyor motor	2.2kw
Machine size	4700x1900x1500mm
Machine weight	7000kgs
Total power	45.4kw
Remark	Including 6 meter veneer conveyor

3. More Pictures



Welcome to Contact
