• Model NO.：MX7216A, MX7216B, MX7216C,MX7216D
• After-Sales Service：24 Hours Technical Support by Email, Call, Video
• Warranty Time：Offer Free Spare Parts and Service Within 12 Month
• Working Experience：Twenty Years′ Experience
• Range of Cutting Diameter：Diameter 1170-1600mm
• Max Cutting Thickness：140mm
• Transport Package：Standard Package, Be Made According Cutomer Need
• Specification：1900*1500*1600mm
• Trademark：XINLIHUI Open Type Four Sides Hydraulic Clamp Carr
• Origin：Qingdao City
• HS Code：84659100
• Production Capacity：100,Week

Basic Info.

Model NO. MX7216A/ MX7216B/ MX7216C/MX7216D After-Sales Service 24 Hours Technical Support by Email, Call, Video Warranty Time Offer Free Spare Parts and Service Within 12 Month Working Experience Twenty Years′ Experience Range of Cutting Diameter Diameter 1170-1600mm Max Cutting Thickness 140mm Transport Package Standard Package, Be Made According Cutomer Need Specification 1900*1500*1600mm Trademark XINLIHUI Open Type Four Sides Hydraulic Clamp Carr Origin Qingdao City HS Code 84659100 Production Capacity 100/Week

Product Description

There are four modles for this type of shaper, it is a complete wood copying shaper, for the big leisure interest or the joinery and woodware trade. Making your own wooden mouldings is a profitable form of wood processing for most woodware makeing. With a MXZ-71160 you have everything you need for getting started with a much sought-after production. The machine is easy to use and easy to own. You can plane and mould the timber in one operation.You can also order your own design or reproduce old profiles, which can be of great value for you.
Parameter of model MX7216A/ MX7216B/ MX7216C/MX7216D

Modle	MX-7216A	MX-7216B	MX-7216C	MX-7216D
Range of cutting diameter	1170-1600mm	1170-1600mm	1170-1600mm	100-1500mm
Processing length	100-1000mm	100-1000mm	100-1000mm	100-1500mm
Max retangular cutting	2:1	2:1	2:1	2:1
Max cutting thickness	140	140	140mm	140mm
Working table size	Dia 1170mm	Dia 1170mm	Dia 1170mm	1200*1200mm
Cutter spindle diameter	35mm	35mm	35mm	35mm
Guiding roller diameter	100mm	100mm	100mm	100mm
Cutter spindle speed	9000 rpm	9000 rpm	9000 rpm	9000 rpm
Working table speed	1.5-6 r/min	1.5-6 r/min	1.5-6 r/min	1.5-6 r/min
Main spindle motor power	4Kw * 2pcs/5.5kW* 2pcs	4Kw * 2pcs/5.5kW* 2pcs	4Kw * 2pcs/5.5kW* 2pcs	4Kw * 2pcs/5.5kW* 2pcs
Working table driving motor power	1.5kW	1.5kW	1.5kW	1.5kW
Working air pressure	0.6-0.8Mpa	0.6-0.8Mpa	0.6-0.8Mpa	0.6-0.8Mpa
Dust outlet diameter	100mm * 2 pcs	100mm * 2 pcs	100mm * 2 pcs	100mm * 2 pcs
Dimensions	1900*1500*600mm	1900*1500*600mm	1900*1500*600mm	1900*1500*600mm
Weight	1800KG	1600KG	1170KG	1170KG

Detail machine pictures, all photoes are for 100% real shooting ! For more pictures, video and details, please email me!
3 Product show:

Feature:
Safety: avoid operators' hands close to the highly rotating cutter and minimize working accident during operation
Efficiency: operator simple load automatic material discharge, improve productivity and efficiency, reduce labor intensity
Environmental protection: united dust collecting device provide nearly- free working environment and slove dust collection difficulty in normal shaper production
