Good Supplier Wood CNC Router Woodworking CNC Machine
Jinan Firm CNC Equipment Co., Ltd.- Type：Engraving Router
- Spindle Layout：Spindle Over
- Spindle Number：Single-Spindle
- Feed Mode：Manual
- Controlling Mode：CNC
- Certification：CE, ISO, FDA
Base Info
- Model NO.：FM1325
- Customized：Customized
- Condition：New
- Color：Customized
- Table Size(Mm)：1600*3100
- Engraving Area：1300*2500*200
- Spindle Power：3.0kw Water Cooling Spindle
- Spindle Rotate(Rpm)：6000~24000
- Motor Driver：Stepper Motor
- Engraving Speed(Mm/Min)：8000~12000mm,Min
- Machine Structure：Industry Square Tube Structure
- Support Format：G Code or Hpgl
- Working Voltage：AC220V,50Hz or 380V,50Hz
- Working Form：Full-Automatic
- Transport Package：Wooden Box
- Specification：CE SGS ISO
- Trademark：FIRMCNC
- Origin：Jinan, China
- HS Code：8465990000
- Production Capacity：100 Sets,Month
Description
Basic Info.
Model NO. FM1325 Customized Customized Condition New Color Customized Table Size(Mm) 1600*3100 Engraving Area 1300*2500*200 Spindle Power 3.0kw Water Cooling Spindle Spindle Rotate(Rpm) 6000~24000 Motor Driver Stepper Motor Engraving Speed(Mm/Min) 8000~12000mm/Min Machine Structure Industry Square Tube Structure Support Format G Code or Hpgl Working Voltage AC220V/50Hz or 380V/50Hz Working Form Full-Automatic Transport Package Wooden Box Specification CE SGS ISO Trademark FIRMCNC Origin Jinan, China HS Code 8465990000 Production Capacity 100 Sets/MonthProduct Description
Good Supplier Wood CNC Router Woodworking CNC Machine
Advantages:
1. Free samples(I can help you process samples for free.
2.Advertising/artwork/woodworking
3.CE, SGS,ISO
4.High precision
5.High sensitivity
6.High efficiency
7. Warranty: 1 year
8.Door-to-door technical service and 24 hours technology online support
Technical Parameters:
| No. | Description | Parameter |
| 1 | Working Area | 1300mmx2500mmx200mm |
| 2 | Dimension(L*W*H) | 1620mm×3300mm×1500mm |
| 3 | X,Y,Z Traveling Positioning Accuracy | ±0.02/300mm |
| 4 | X,Y,Z Repositioning Accuracy | ±0.02mm |
| 5 | Table Surface | T-slot and vacuum combined table |
| 6 | Table Size | 1420mm×3000mm |
| 7 | Inverter: | Chinese Fuling Inverter/Taiwan Delta Inverter |
| 8 | Spindle | 3KW Chinese Hanqi water colling spindle |
| 9 | Limit switch | Japan Omron limit switch |
| 10 | Oil LubricationSystem | Manual |
| 11 | X, Y,Z Transmission | Taiwan Hiwin Square Rail and TBI Ball Screw |
| 12 | Max. Power Consumption | 6KW |
| 13 | Max. Rapid Travel Rate | 33000mm/min |
| 14 | Max. Working Speed | 25000mm/min |
| 15 | Spindle Power | 3KW(optional:2.2KW/3KW) |
| 16 | Spindle Speed | 0-24000RPM |
| 17 | Motors | 450B stepper |
| 18 | Working Voltage | 220V/380V |
| 19 | Command Language | G Code |
| 20 | Operating System | DSP System/NC-studio |
| 21 | Computer Interface | USB |
| 22 | Collet | ER25 |
| 23 | X,Y Resolution | <0.03mm |
| 24 | Software Compatibility | Artcam Software/Type3 Software |
| 25 | Running Environment Temperature | 0 - 45 Centigrade |
| 26 | Relative Humidity | 30% - 75% |
| 27 | Packing Size | 2120mmX3700mmX1900mm |
| 28 | N.W. | 1500KG |
| 29 | G.W. | 1600KG |
Application Industry and Materials:
Advertising industury:Cnc router can engrave all kinds of signage,logo products,trademarks,nameplates,badges,decorative gift,embossed
medals,certificates,souvenirs,photo frames,furniture decoration,PVC plates, PCB boards
(drilling and engraving),Double color boards,acrylic etc.
Woodworking Industry:Cnc router can be used for solid wood furniture,mahogany furniture,
MDF paint doors,solid wood doors,composite doors,cupboard doors and windows,beside
cabinets,folding screen etc.
Artwork industry: in the wood, bamboo, organic board, double color plate, crystal and other materials on a variety of exquisite patterns and text engraving.
Packing & shipment :
Save space as much as possible for container loading.
Inside:Water-proof Plastic Film Package With Foam Protection
Outside:Solid Seaworthy Wood Box Package
Below: Steel Tube
After sale service
1. 24 hour Technical support by phone, e-mail or MSN around the clock.
2. Friendly English version manual and operation video CD disk.
3.7-15 working days after down payment or full payment.
4. Machine will be adjusted before it is delivered; operation disk/CD was included.
5. Our technician can give you remote guide online (Skype or MSN) if you have any question.
6. Engineers available to service machinery overseas, seller and buyer discuss the charges.
Company information:
FIRMCNC Group located in Jinan,Shandong PR, Founded in 2003. Leader of laser marking machine appliance manufacture.
We are an all-round enterprice,which is comprehensive in R&D, manufacture, and sales on laser marking machine appliances.
JINAN FIRM CNC EQUIPMENT CO.,LTD
A-505Jingliu Road, Huaiyin District, Jinan City, Shandong Province, China.
Tel: 0086-0531-69986330 Fax : 0086-0531-69986330
Website: http://firmcnc.en.made-in-china.com
firmcnc.en.made-in-china.com
Cell phone: +86-13954117091
