Woodworking Machine Double Side Two Double Head Wide Belt Sanding Sander Machine
Qingdao Haozhonghao Woodworking Machinery Co., Ltd.- Type：Belt Wood Sander
- Automatic Grade：Automatic
- Variable Speed：Variable Speed
- Certification：CE, ISO
- Customized：Customized
- Condition：New
Base Info
- Model NO.：MM5613R
- Color：White Wide Belt Sanding
- Usage：Wide Belt Sanding Machine
- Unit：Double Side Wide Belt Sanding
- Motor Power：165kw
- Sanding paper Size：1350*2800mm
- Transport Package：Plastic Bags
- Specification：3000*1700*3000mm
- Trademark：HZH
- Origin：China
- Production Capacity：2 Sets,Month
Description
Basic Info.
Model NO. MM5613R Color White Wide Belt Sanding Usage Wide Belt Sanding Machine Unit Double Side Wide Belt Sanding Motor Power 165kw Sanding paper Size 1350*2800mm Transport Package Plastic Bags Specification 3000*1700*3000mm Trademark HZH Origin China Production Capacity 2 Sets/MonthProduct Description
| Model | MM5613R | MM5613RP |
| Max working width | 1300mm | 1300mm |
| working thickness | 5-100mm | 5-100mm |
| Working length | ≥600mm | ≥600mm |
| working precision | ±0.08mm | ±0.08mm |
| size of abrasive belt | 1350*2800mm | 1350*2800mm |
| speed of abrasive belt | 25m/s | 25m/s |
| Roller diameter | Φ320mm | Φ240mm |
| Total power | 165kw | 105kw |
| Main motor power | 75Kw*2 | 45Kw*2 |
| Feeding motor | 11Kw | 11Kw |
| Lifting motor | 2.2Kw | 2.2Kw |
| Brush motor | 0.75kw*2 | 0.75kw*2 |
| working air pressure | 0.5-0.8Mpa | 0.5-0.8Mpa |
| volume of dust collector | 28000 m³/h | 28000 m³/h |
| weight | 11T | 12T |
| Overall dimension | 3000*1700*3000mm | 3000*1900*3000mm |
| Voltage | 380V 50Hz | 380V 50Hz |
