Woodworking Machinery

Professional Electric High Quality Disc Wood Crusher

ZHENGZHOU YUFENG HEAVY MACHINERY CO., LTD.
  • Power Source:Electric
  • Condition:New
  • Model Number:400
  • Blade Qty:4
  • Output Capacity:0.4-0.8t,H
  • Blade Size:150mm

Base Info

  • Model NO.:400
  • Cutter Head Dia:400mm
  • Max Log Dia:100mm
  • Feed Inlet Size:150*150mm
  • Main Motor Power:11kw
  • After-Sales Service Provided:Engineers Available to Service Machinery Overseas
  • Certification:CE, ISO
  • Transport Package:Disc Chipper No Packing or Customed
  • Specification:400
  • Trademark:Yufchina
  • Origin:Henan, China (Mainland)
  • HS Code:84659600
  • Production Capacity:100 Set,Sets Per Month Disc Chipper

Description

Basic Info.

Model NO. 400 Cutter Head Dia 400mm Max Log Dia 100mm Feed Inlet Size 150*150mm Main Motor Power 11kw After-Sales Service Provided Engineers Available to Service Machinery Overseas Certification CE, ISO Transport Package Disc Chipper No Packing or Customed Specification 400 Trademark Yufchina Origin Henan, China (Mainland) HS Code 84659600 Production Capacity 100 Set/Sets Per Month Disc Chipper

Product Description

Professional electric high quality disc wood crusher


Wood chipper Technical Parameter:
modelPX400PX680PX850PX1000PX1150PX1300PX1600
cutter head dia. (mm)4006808501000115013001600
cutter head thickness (mm)≥5≥5≥8≥9≥10≥10≥12
blade size (mm)150200250300340420500
blade qty (pcs)4446666
feed inlet size (mm)150*150150*150200*200230*230270*270350*350420*420
max. log dia.(mm)100100160180200250300
wood chips length/thickness (mm)15-35/2-315-35/2-315-35/3-715-35/4-1015-35/4-1015-35/4-1015-35/4-10
feed method
oblique/level

oblique/level

oblique/level

oblique/level

oblique/level

oblique/level

oblique/level
discharge method
top/bottom

top/bottom

top/bottom

top/bottom

top/bottom

top/bottom

top/bottom
output capacity (t/h)0.4-0.82-53-58-1010-1510-1520-25
main motor power (kw)112230/45555575-90110-132

Disc wood chipper introduction:
     Disc wood chipper is one kind of special equipment for producing wood chips, which is widely used in the raw material preparing process in the factories of flake board, fiberboard, and papermaking and wood chips making plants.
     It can process the wood, branch and bamboo into chips with the advantage of low investment and energy consumption. Disc wood chipper alsorb essence of domestic and abroad, using high wear-resistant rotor, feed wood log to wood chipper directly, grinding into small chips, high production capacity and long service life.
Material of wood chipper :
    •Any kind of wood log ,wood bar ,not adapt the wood board,small branch.
    •Any moisture wood log or wood bar can be chipped ,the finished wood chips is very uniform of 1-5cm.
Disc Wood Chipper Application:
     The Disc Chipper is the special equipment which used for reducing wood (it mainly deal with round logs, branches, bamboo, cotton stalks) into smaller and uniform wood chips, which is used as material in pulp & paper industry, biomass industry, fiber and particleboard plants, and also well suitable as fuel for high intensity burning in modern heating plants.

Our Services
Pre-sale
1. Depending on customer's requirement, we insist on "making profit at lowest investment" and gives best solution as per the customer's special demand.
2. Design the most reasonable project and maximum customers' profit.
3.Provide engineers to scene to plan work site if the customer needed.
4. Provide equipment list, design drawing, construction drawing, equipment install drawing.

During-sale
1. Depend on scene, draw design drawing , construction drawing, equipment install drawing, civil work detailed drawing for references, operating manuals, maintenance video, etc
2.Manufacturing products strictly on contract while customer constructing.
3. Production progress report each week with detailed description and photos, including raw materials tables, process and deep process record, testing data sheet, etc.
4. Testing all the equipments by witness of the customer ex-work, delivery, customer acceptance.

After-sale
1. Provide engineer to work site guiding install, debugging and commissioning.
2. Test equipment after installation, training operators for free, remind notice in operating.
3. Regularly returning visit to the customers.
4. Within warranted period, we take charge of everything if any quality problems. After the warranted period, we still focus on the plant running and services.
5. Response customer's questions within 1 working day, give effective solutions within 3 working days, go into action with 5 working day.

That's our promise, as we know quality and service both are important for long-term's development and cooperation.

If you have any questions, please feel free to contact us.

Zhengzhou Yufeng Heavy Machinery CO.,LTD
Tel: +86 371 60395600
Fax:+86 371 67681159
Website: yufengzg.en.made-in-china.com
Address:West Section of Gongye Road,Shangjie Industry Area,Zhengzhou,Henan,China
