ZICAR Full Automatic Panel Saw Machine MJ6230B
JAYA INTERNATIONAL CO., LTD.- Type:Table Panel Saw
- Power Type:Electric
- Layout:Horizontal
- Controlling Mode:CNC
- Automatic Grade:Automatic
- Precision:High Precision
Base Info
- Model NO.:MJ6230B
- Certification:CE, ISO
- Customized:Customized
- Condition:New
- Color:Customized
- Max incising length:2550mm
- Max incising thickness:48mm
- Main blade motor power:5.5kw
- Outer diameter of main blade:300mm
- Inner diameter of main blade:30mm
- Revolving speed of mian blade:4700rpm
- Outer diameter of secondary blade:120mm
- Inner diameter of secondary blade:20mm
- Revolving speed of secondary blade:6700rpm
- Cutting speed:15m,min
- Returning speed:15m,min
- Air pressure:0.6MPa
- Machine outline size:1000X4544X1350mm
- Total power:7.5kw
- Net weight:about 1700kg
- Transport Package:Wooden Package
- Specification:1000x4544x1350mm
- Trademark:ZICAR
- Origin:China
- HS Code:8465990000
- Production Capacity:500sets,Month
Description
