Hydraulic Hot Press Machine /Plywood Hot Press Machine

Linyi Sin San Lin Smart Machinery Co., Ltd.
  • Work Forms：Hydraulic Pressure
  • Processing Technics：Hot Press
  • Structure：Frame Type
  • Pressing Shape：Flat Press
  • Platen Surface Pressure：High Pressure
  • Pressing Layer：Multi Layer

Base Info

  • Work Mode：Period
  • Controlling Mode：CNC
  • Automatic Grade：Automatic
  • Certification：CE, ISO
  • Voltage：380V
  • Transport Package：Standard Export Packaging or as Per Your Request
  • Specification：1220*2440mm Panel
  • Trademark：METRO MACH
  • Origin：Shandong, China
  • Production Capacity：15 Layer

Description


1.Adopt the composited frame special designed for exporting container,and welded by national standard steel plate,reasonable structure,force points are strictly calculated,good rigidity can bear high pressure and no deformation.

2 .Micro computer control,high automatic degree,easy to operate and maintenance,long working life.

3.Hydraulic control system adopts imported hydraulic units,fast press,accurate and high efficiency.

4.We can supply all kind of sizes such as 4' X 8' feet, 3' X 6' feet, 5' X 5' feet, 6' X 6' feet, 6' X 8' feet and so on.

5.The main equipment for producing the plywood and film faced plywood.





Technical Parameters:
 Machine name 400Tons hot press machine for plywood Machine model BY214X8/4-15IId Boards in-feeding direction Horizontal Layers counting 15Layers Distance between hot platens 70mm Numer of hot platens 16PCS Dimension of hot platens 1370X2700X42mm Number of plunger oil cylinders 2 PCS Diameter of plunger oil cylinders Φ320mm(Made in Wuxi city) Stroke of plunger oil cylinders 1050mm Allowed pressure ≤25MPa Empty closing time About 29 s Low pressure pump flowing 355L/min Allowed pressure ≤5MPa Power 11Kw High pressure pump flowing 35L/min Power 7.5Kw Specific pressure 12.3kgf/cm2 Boards size 1280X2560mm Machine net weight About 33500Kgs Machine overall dimension 3590X1370X4200mm Control way Automatic pump station Frame Composited main frame Thickness of upper and lower crossbeams 1000,900mm Steel plate thickness of crossbeams 35mm Steel plate thickness of uprights 35mm Thickness of active crossbeam 400mm Steel plate thickness of active crossbeam 30mm




Packing&Shipping

Hydraulic Hot Press Machine /Plywood Hot Press Machine


Pre-sale services:
1) Provide the free consultation of the equipment
2) Provide the standard device and the flow chart
3) According to the clients' special requirement, offering the reasonable plan and free design to help to select the equipment.
4) Welcome to visit our factory
Services during the sales:
1) Inspect the machine before leaving the factory.
2) Oversea install and debug the equipment
3) Train the first-line operator.
After sale services:
1) 24 hours online service
2) Provide the video  with Install and debug the equipment
3) Provide technical exchanging
