New Style! Wood Carving CNC Router Machine Price 1325
SHANDONG RUIJIE CNC TECHNOLOGY GROUP CO., LTD.- Type：Engraving Router
- Spindle Layout：Vertical
- Spindle Number：Single-Spindle
- Feed Mode：Mechanical
- Controlling Mode：CNC
- Certification：CE, ISO, FDA
Base Info
- Model NO.：RJJ1325B
- Customized：Customized
- Condition：New
- Color：Customized
- Brand Name：Ruijie
- Model Number：Rj1325b
- Voltage：380V and 220V
- Power(W)：3.0kw or Optional
- Working Area：1300*2500mm or Optional
- Guide Rails：Linear Guide Rails
- Motors and Drivers：Leadshine Stepper Motors or Servo Motors
- Control System：DSP, Weihong, Mach3 or Optional
- Transmission：Xy Rack Gear, Z Ballscrew
- Table：T-Slot Table or Vacuum Table
- Transport Package：Standard Plywood Package
- Specification：CE, ISO, SGS
- Trademark：RUIJIE
- Origin：Jinan Shandong
- HS Code：8479899990
- Production Capacity：1000 Sets Per Month
Description
Items
Basic configuration
Optional item
Certificate cnc router 1325 woodworking machine with vacuum table
CE
XY-axis working area
1300*2500mm
Designed as your requirement
Material
Square steel tube machine bed,
Cast aluminum gantry
Moving way
Gantry moving
Table moving
Working table
Aircraft aluminum with T slot
Vacuum table
Guide way
XYZ-axis linear guide rail
Driving mode
XY rack gear, Z ball screw
Z-axis working area
130mm or 230mm
Lower or higher as you need
Max traveling speed
8000mm/min
Engraving speed
6000mm/min
Mechanical precision
0.05mm
Driving method
Stepper motor(XYZ:86BYGH450A)
Bigger power or servo motors
Water cooling system
Water pump for spindle
Spindle
3.0KW water cooling
4.5KW/5.5KW or air-cooled
Spindle speed
0-24000rpm
Collet type
ER20
Tools diameter
3.175mm, 4mm, 6mm,8mm,10mm,12.7mm
Control system
DSP
NC Studio or MACH3
Design software when delivery
Artcam
Compatible design software
Artcam, Type3, Ucancam, JDPaint, MasterCAM
Command
G code ,U00, mmg nc,etc
Running ambient temperature
0-45ºC
Relative humidity
30%-75%
Voltage
AC 380 220V,50/60Hz, single phase
Auto tool calibration
For Z-axis
Tools
15pcs for wood/advertising
Other tools as you need
Accessories
Water pump, tools, power line, USB line, brush, spanner, collet, fixtures, user manual CDs.
Other optional items
Original control system, air cooling spindle, dust colletor, auto oiling system, computer cabinet, rotary axis, wireless handwheel
