Low Cost Small CNC Router (DW3020)
Jinan Dwin Technology Co., Ltd.- Type：Engraving Router
- Spindle Layout：Vertical
- Spindle Number：Single-Spindle
- Feed Mode：Manual
- Controlling Mode：CNC
- Certification：CE
Base Info
- Model NO.：DW3020
- Customized：Customized
- Condition：New
- Color：Make The Machine Color as Customers Requirement
- Model：3020 Mini CNC Router
- Spindle Power：240W
- Working Area：300X200mm
- Motor：Leadshin Stepper Motor
- Control System：Nc Studio
- Software：Types3
- Tranmission：Circular Rail
- Table：Aluminum Table
- Weight：23kg
- Warranty：12 Months
- Transport Package：Playwood Box
- Specification：300x200mm
- Trademark：DWIN
- Origin：Jinan City Shandong Province China
- HS Code：8465990000
- Production Capacity：100set,Month
Description
Type
mini cnc router
Model
DW3020 cnc router
Machine Body
Whole cast iron
Work Dimensions
300x200x80mm
Z-axis Working Area
80mm
Max. Feeing Height
80mm
Cut Thickness of Material
<20mm
Max. Speed
4200mm/min
Working Speed
0-3000mm/min
Mechanical Precision
0.01mm
Software
March3
Max. Power Consumption
900W
Power Supply
AC220V/50Hz and others
Driver Type
Leadshine Stepper Motor
Memory
1MB
Spindle
240W spindle
Spindle Speed
0-8000RPM/min
Blade Diameter
1-6m
Control System
Artcut or Weihong (NCSTUDIO) or DSP(USB interface
Command
G code, u00, mmg, plt
Interface
RS232
Running Circumstance Temperature
0-45
Relative Humidity
30%-75%
Warranty :
1) The machine guarantee is 12 months.
2) 24 hours technical support by email or calling.
3) Friendly English verson manual and operation video CD disc.
