• Model NO.：DW3030
• Customized：Customized
• Condition：New
• Color：Customized
• Working Arae：300mm*300mm
• Z Axis Working Area：60mm
• Working Speed：0 - 3000mm,Min
• Software：Type 3 Software, Artcut Software, Artcam
• Driver Type：Stepper Motor
• Spindle Speed：0 - 24000rpm
• Spindle Power：1.5kw
• Control System：March3(Option:DSP Control System)
• Command：G Code, U00, Mmg, Plt
• Machine Structure：T-Slot Table(Vaccum Table for Choice)
• Transport Package：Playwood Box
• Specification：CE, SGS
• Trademark：DWIN
• Origin：Jinan City Shandong Province China
• HS Code：8465990000
• Production Capacity：50 Sets,Month

Basic Info.

Model NO. DW3030 Customized Customized Condition New Color Customized Working Arae 300mm*300mm Z Axis Working Area 60mm Working Speed 0 - 3000mm/Min Software Type 3 Software, Artcut Software, Artcam Driver Type Stepper Motor Spindle Speed 0 - 24000rpm Spindle Power 1.5kw Control System March3(Option:DSP Control System) Command G Code, U00, Mmg, Plt Machine Structure T-Slot Table(Vaccum Table for Choice) Transport Package Playwood Box Specification CE, SGS Trademark DWIN Origin Jinan City Shandong Province China HS Code 8465990000 Production Capacity 50 Sets/Month

Product Description

                                                     cnc small stone engraving router machine (DW3030)


Features:

1.The machine adopts international advanced accurate guide rail,slide pre-tight installment (guaranteed no space is between the slides) and German original ball screw to realize steady movement ,high precision and small vibration.

2.March 3 control system that adopted by the machine has the advantages of break point and break power continue engraving,assisned G code engraving ,etc.(The DSP handle operation system which enables the machine work without the computer can be choosen .)

Applicable materials:

PVC board,ABS, double-color board,acrylic,MDF,stainless steel,copper,alumnium, zinc etc materials.

Technical parameters:

Machine body:	DW3030  Whole cast iron
Work dimensions:	300 x 300 x 60mm
Body dimensions:	600 x 600 x 600mm
Z-axis working area:	60mm
Max. Feeding height:	60mm
Cut thickness of material:	<20mm
Max.Speed:	4200mm/min
Working speed:	0 - 3000mm/min
Mechanical precision:	0.01mm
Software:	Type 3 software, Artcut software, Artcam software
Max. Power consumption:	900W
Power supply :	AC 220/50Hz
Driver type:	Stepper motor
Memory:	1MB
Spindle:	1.2KW variable speed, water cooled motor
Spindle speed:	0 - 24000RPM
Blade diameter:	1 - 6m
Control system:	March3 or Wei hong (NCSTUDIO) or DSP (USB interface)
Command:	G code, u00, mmg, plt
Interface:	RS232

Guarantee & After sales service:
Professional Service
From producing in our factory to shipping the goods directly to your port or company, we supply all-in-one service for our customers.
With the rich experience of dealing with shipping issue and custom clearance, we can make the most economical delivery plan for you and ensure the quick leading time.
No matter your quantity is our MOQ or very big, we take each customer as the only one.

Warranty for the machine
1. 18 months quality guarantee for the main parts of the machine, excluding consuming parts, and the main parts shall be changed free of charge during the warranty time
2. Lifelong maintenance for the machine, and lifelong technical support from sophisticated English-speaking engineer team.
3. Free training course at our plant
4. We will provide the machine consuming parts with factory price when you need replacement.
5. 24 hours online service each day, free technical support.
