Panel Saw of Woodworking machine SMV8D
Qingdao Yongqiang Woodworking Machinery Co., Ltd.- Type：Table Panel Saw
- Power Type：Electric
- Layout：Horizontal
- Controlling Mode：Artificial
- Automatic Grade：Manual
- Precision：Precision
Base Info
- Model NO.：SMV8D
- Certification：CE, ISO, FDA
- Customized：Customized
- Condition：New
- Color：Customized
- Transport Package：Wooden Box
- Specification：CE
- Trademark：unisunx
- Origin：China
- HS Code：84659100
- Production Capacity：5000,Year
Description
Basic Info.
Model NO. SMV8D Certification CE, ISO, FDA Customized Customized Condition New Color Customized Transport Package Wooden Box Specification CE Trademark unisunx Origin China HS Code 84659100 Production Capacity 5000/YearProduct Description
| Dimensions sliding table | 3200×405mm |
| Gross cut capacity | 3200mm |
| Width of cut between saw blade and rip fence | 1250mm |
| Saw blade φ | 300mm(φ250-φ300) |
| Height of cut φ300mm | 80mm |
| Height of cut with saw blade φ300mm at 45° | 55mm |
| Speed of main saw blade | 3000/4000/5000rpm |
| Spindle diameter | 30mm |
| Tilling saw blade | 0-45° |
| Main motor | 5.5kw |
| Scoring saw blade | 120mm |
| Speed of scoring saw blade | 8000r/min |
| Spindle of scoring saw | 20mm |
| Motor | 0.75kw |
| Net weight | 770kg |
| Gross weight (wooden packing case) | 900kg |
| Overall dimensions | 3250×3500×900mm |
