Double Side Planer CH206h
Shijiazhuang Chancsmac Machine Technology Co., Ltd.- Warranty：One Year
- Type：Double-sided Pressure Planer
- Working Depth：＜100mm
- Working Width：430mm
- Drivetrain：Main Drivetrain
- Enter Method：Mechanical
Base Info
- Model NO.：CH206H
- Motor Power：5-10Kw
- Spindle Speed：＞5000rpm
- Process Type：Medium-Sized Processing
- Certification：CE, ISO
- After-sales Service：Free Service on Internet
- Working Thickness：200mm
- Mini Working Length：260mm
- Cutting Shaft Diameter：101mm
- Spindel Speed：5000r,Min
- Feeding Speed：0-16m,Min
- Top &Bottom Spindle Motor Power：11,7.5kw
- Feeding Motor Power：3kw
- Total Weight：2800kg
- Transport Package：PE Film
- Specification：CH204F
- Trademark：CHANCSMAC
- Origin：China
- Production Capacity：20 Sets,Month
Description
