• Model NO.：1325, 1212, 1224, 1530, AND customized
• Relative Humidity：30% - 75%
• Transport Package：Plywood
• Specification：1300*2500*200
• Trademark：sea eagle
• Origin：China
• HS Code：8465990000
• Production Capacity：2000 Sets,Year

Basic Info.

Model NO. 1325, 1212, 1224, 1530, AND customized Relative Humidity 30% - 75% Transport Package Plywood Specification 1300*2500*200 Trademark sea eagle Origin China HS Code 8465990000 Production Capacity 2000 Sets/Year

Product Description

Give me your inquiry for machine catalog and quotation details
We can make machine following your demand!!!


give me your inquiry for machine catalog and quotation details
we can make machine following your demand!!!





Technical parameter:

ITEM	1325 CNC ROUTER	OPTIONAL PARTS
X Y Z Working area	1300*2500*200mm	Other size is optional
Table size	1460*2940mm
X,Y,Z Traveling PositioningAccuracy	±0.01/300mm
X,Y,Z Repositioning Accuracy	±0.01 mm
Table Surface	T-slot, hold the material by clamps	vacuum table
Machine body	Thick,strong and high quality steel tube welded
X,Y axis driving way	Rack and Pinion /Linear square guide rails&blocksimported from Taiwan, HIWIN brand
Z axis driving way	Ball screw / Linear square guide rail and blocks  imported from Taiwan, HIWIN brand
Max. Power Consumption	2.0kw(without spindle)
Max. Rapid Travel Rate	33,000mm/min
Max. Working Speed	25,000mm/min
Spindle Power	3.0KW/4.5KW/6KW water cooling  spindle	Italy HSD or Chinese  air cooling spindle
Spindle Speed	0-24000 RPM	0-18000RPM
Inverter	Fuling	Yaskawa, Panasonic, Deltaor others
Working Voltage	AC380V/50-60Hz/3PH	AC220V/50-60Hz/ Single or 3 phase
Command Language	G Code
Control system	DSP and control handle	Ncstudio, Mach 3,  Syntecor others
Computer Interface	USB	PCI
X,Y Resolution	< 0.01mm
Software Compatibility	Type3/ Ucancame V9 software  (Option: Artcam Software)
Dust collector	2.2KW with 2 bags	3KW/4KW
Vacuum pump	5.5KW, water cooling	Dry cooling
Running Environment Temperature	0°-45°
Relative Humidity	30%-75%
Packing Size	20300*3100*1740mm
Net weight	1500kg
Gross weight	1800kg

machine Feature
1.Well-known HQD air cooling spindle(optional HSD spindle), high precision, long life time, steady working, easy to start up.
2.Thicken square pipe structure, well welded,no distortion for whole structure.
3.Adopt Taiwan square orbit, double slippers. Bearing heavy, working steadily high precision, and long life time.
4.DSP controller system with USB interface, working without connecting with computer during working and easy to control.
5.This machine can engrave any design,support scanners,direct support ,Art CAM,Type3,Wen tai,carving and many other G-code format generated by CAD/CAM
6.Adopt high speed stepper motor and drivers,and two motors for Y axis. Max speed is 30M/MIN.

Give me your inquiry for machine catalog and quotation details
we can make machine following your demand!!!


Parts




Application

Woodworking	wooden door and furniture, windows, tables and chairs,cabinets and panels, 3D wave plate, MDF,computer desk,musical instruments,etc
Advertising	billboard, logo,sign,3D characters cutting,acrylic cutting,LED/neon channel,literal-hole cut,lightbox mold,stamp,mould,etc
Die industry	copper sculpture,aluminum engrave,metal molds,plastic sheeting,PVC ,etc
Decoration	acrylic, density board, artificial stone, organic glass, soft metals like aluminum and copper, etc.

samples



Give me your inquiry for machine catalog and quotation details
We can make machine following your demand!!!


Optional parts of wood carving machine

1.Reducer:Germany Eisele/Japan Shimpo/Taiwan APEX
2.Lubrication system:Manual or automatic lubrication system
3.Vacuum pump:Germany Becker/Tongyou vacuum pump
4.Rotary device: Dimensions can be customized
5.Dust collector:Single or double packet dust collector
6.Cooling system:Simple cooling or mist cooling system

About our service:
1, Before-sale:we will try to know your requests about what work you will do
   and help you choose the most suitable machine specification & give you the best solution.
2.During production: we will send photos of machines during production. so customers can know more details
   about the procession of making their machines. and give them suggestions.
3.Before shipping:we will confirm the specification of order to avoid the mistake and we will test & adjust the machine until it has the best performence.
4.After shipping: we will give you the tracking information of the sea vessel
   so customers can know when it will arrive at your port and make enough preparation.
5.After arrival: we will confirm with you if machine is in good condition. and see if any spare parts were broken during sea shipping then help to solve the insurance
6.About training: there are some manual and video about how to install & use machine , if you have any questions
   you can contact me any time, then i arrange our professional technicians to help you by video, pictures,call or email.
7. About warranty: we offer 2 years warranty for whole machine and half year warranty for spindle.
   if any parts of our machine is broken. we will replace it for free.
8. Service in life-time: we hope our machine can bring perfect performance in life-time, of course no matter how many years passed, you always can contact me, we can give you any technical support in the future life-time.
