Woodworking Machine (SMV8D-X)

Qingdao Yongqiang Woodworking Machinery Co., Ltd.
  • Type：Table Panel Saw
  • Power Type：Electric
  • Layout：Horizontal
  • Controlling Mode：Artificial
  • Automatic Grade：Automatic
  • Precision：Precision

Base Info

  • Model NO.：SMV8D-X
  • Certification：CE, ISO, FDA
  • Customized：Customized
  • Condition：New
  • Color：Customized
  • Transport Package：wooden boxes
  • Specification：CE
  • Origin：China
  • HS Code：84659100

Description

Basic Info.

Model NO. SMV8D-X Certification CE, ISO, FDA Customized Customized Condition New Color Customized Transport Package wooden boxes Specification CE Origin China HS Code 84659100

Product Description

Dimensions sliding table3200×435mm
Gross cut capacity3200mm
Width of cut between saw blade and rip fence1300mm
Saw blade φ300mm(φ250-φ300)
Height of cut φ300mm80mm
Height of cut with saw blade φ300mm at 45°55mm
Speed of main saw blade3000/4000/5000rpm
Spindle diameter30mm
Tilling saw blade0-45°
Main motor5.5kw
Scoring saw blade120mm
Speed of scoring saw blade8000r/min
Spindle of scoring saw20mm
Motor0.75kw
Net weight1080kg
Gross weight (wooden packing case)1180kg
Overall dimensions3350×3600×900mm
