2/6/8/10/12 Heads Multi-Spindle Woodworking Engraving Machine/CNC Router Machine
Hefei Aquila CNC Equipment Co., Ltd.- Condition:New
- Certification:ISO, CE
- CNC or Not:CNC
- Voltage:380V
- Working Stoke:2700mm*2000*160mm
- Feeding Height:160mm-250mm
Base Info
- Model NO.:ZS-2720
- Transport Package:Plywood Case Package
- Specification:2000kgs
- Trademark:Mars
- Origin:China
- HS Code:8458110090
- Production Capacity:300sets,Month
Description
Basic Info.
Model NO. ZS-2720 Transport Package Plywood Case Package Specification 2000kgs Trademark Mars Origin China HS Code 8458110090 Production Capacity 300sets/MonthProduct Description
Multi-Spindle Woodworking Engraving Machine/CNC Router MachineKeywords: 15 years experience of production
ISO9001:2008, CE, SGS, AAA Level Enterprise which Honors Contract
Three Brands: Mars, Golden Eagle, Boiro
Technicist who go abroad to offer after-sale service
Technical Parameters:
Model | ZS-2720(Can be customized as your needs) |
Working Stoke | 2700mm*2000*160mm |
Feeding Height | 160mm-250mm |
Table Structure | T-slot aluminum |
Body Structure | Thick steel tube welded, w/ tempering |
Spindle Power | 800W~ 3.7KW frequency water-cooling spindle (Air-cooling motor, or Italy imported HSD motor is optional) |
Spindle Speed | 0 ~ 24000 rpm/min |
Engraving Tool | ¢3.175/4/6/12.7mm |
Control System | NC Studio/ DSP |
Drive System | Leadshine servo motor |
Lubrication System | Automatic |
Transmission | XY axis rack and pinion, Z axis ball screw |
Guide Rail | Taiwan Hiwin rectangular linear rail |
Transformer | 630VA |
Max Travelling Speed | 20m/min |
Max Processing Speed | 15m/min |
Dictate Format | G code/ HPGL |
Working Accuracy | ±0.02mm |
Re-positioning Accuracy | ±0.05mm |
Working Environment | Temperature 0ºC ~ 90ºC, Humidity 30% ~ 75% |
Working Voltage | AC380/ 3PH/ 50HZ |
Net Weight | 1500KG (Grey) |
Machine Size | 3400*2600*1700mm (Grey) |
Applicable Scope:
Classical mahogany furniture, white wood European furniture, carved antique furniture, wall hollow, solid wood doors, craft doors, Paint-free doors, cabinet doors, craft windows, variety of tables, sofas, panel furniture, advertising signs, sign making, acrylic cutting, blister light boxes, curtain walls, aluminum, copper, composite board and other non-ferrous metals.
Package and Shipment:
Company Profile:
Certificate:
FAQ:
1).How to get the most suitable machine and best price ?
Please tell the material you want to working on ?
How to working on it ? Engraving ? Cutting ? Or other ?
What's the MAX size of these material ?( length ? Width ? Thickness ?)
2). Do you have the manual of machine ?
Yes,we have by English
3). If we donot know how to use the machine,can you teach us ?
Yes,we will ,if you come to China,we will offer you free training until you can use machine freely. And if you are busy ,we will have the special engineer to your country
