Woodworking Machinery

Great Quality Tree Wood Log Chipping Slicer Machine

Jiangsu Liangyou Zhengda Co., Ltd.
  • Certification:CE, ISO
  • Delivery Detail:30-45 Days After Receive Down Payment
  • Rotor Dia(mm):800
  • Number of Flying Knives(PCS):2
  • Knife Rotor Speed(Rpm):650
  • Feed Speed(M/Min):37

Base Info

  • Model NO.:LYGX Series
  • Capacity(M3/H):3-70
  • Main Motor Power(Kw):30-315
  • Transport Package:Iron Pallet or Depending on Customers′ Request
  • Specification:CE, ISO9001
  • Trademark:FDSP
  • Origin:Jiangsu, China (Mainland)
  • HS Code:8436100000
  • Production Capacity:20 Set,Sets Per Month

Description

Basic Info.

Model NO. LYGX Series Capacity(M3/H) 3-70 Main Motor Power(Kw) 30-315 Transport Package Iron Pallet or Depending on Customers′ Request Specification CE, ISO9001 Trademark FDSP Origin Jiangsu, China (Mainland) HS Code 8436100000 Production Capacity 20 Set/Sets Per Month

Product Description

Great Quality Tree Wood Log Chipping Slicer MachineGreat Quality Tree Wood Log Chipping Slicer Machine
Products introduction of wood chipper:
1. The chipper consists of a base, a knife roll, upper and lower feeding mechanism, feeding device, hydraulic buffer system and electrical control system;

2. The blade is made of special material, high strength and strong wear resistance;

3. The knife roll is processed as a whole, and it is checked by dynamic balance to improve accuracy and run smoothly;

4. The press material system adopts the hydraulic system automatic control, and the feeding system adopts frequency conversion control;

5. The bottom knife seat is made of forgings with high strength and long service life;

6. Patented knife roll structure, the chipping efficiency is increased by 30%-50%, and the main power is reduced by 30%-50%, and the use cost is greatly reduced.
Great Quality Tree Wood Log Chipping Slicer Machine
Main technical parameters:


Data
Model
LYGX213/5LYGX216LYGX218LYGX218DLYGX2110
Rotor Dia(mm)3006508008001000
Number of flying knives(pcs)22222*2
Feed opening size(mm)120*300180*500225*680240*780330*1050
Knife rotor speed(rpm)730590650650550
Feed speed(m/min)3837.2373833
Max dia of logCutting bark120160160190
Wood chips length(mm)2630303030
Capacity(m³/h)8-1610-1815-203875
Main motor power(kw)4555110132220
Feed roller motor power(kw)2*1.12*32*42*5.52*7.5
Weight(kg)120040707000800012500
Overall dimension(L*W*H)3681*870*9004348*2056*12584670*2150*15004670*2250*15152850*2790*1497
Great Quality Tree Wood Log Chipping Slicer Machine

Great Quality Tree Wood Log Chipping Slicer Machine
Great Quality Tree Wood Log Chipping Slicer Machine
Great Quality Tree Wood Log Chipping Slicer Machine

Great Quality Tree Wood Log Chipping Slicer Machine
WHY CHOOSE US?

Our products have passed the SGS,ISO9001:2008,CE certifications.Moreover,we own several patents,such as "utility model patents certificate"and "high-tech products certificate",etc.Our goods exported to many countries and won the good reputation by the high quality and superior service.
