Xs200A Atc CNC Machining Center for Doors Diversified Design
Hefei Aquila CNC Equipment Co., Ltd.- Condition：New
- Certification：ISO, CE, Ce, ISO 9001, Patent Certification
- CNC or Not：CNC
- Voltage：380V
- Process Usage：CNC Non-Conventional Machine Tools
- Movement Method：Contour Control
Base Info
- Model NO.：XS200A
- Control Method：Closed-Loop Control
- Numerical Control：CNC,Mnc
- Processing Precision：0.01~0.02(mm)
- Performance Classification：MID-Range CNC Machine Tools
- Application：Wood, Bamboo, Marble, Organic Board, Color Plates
- Configuration：9kw Air Cooling Spindle + Circular Tool Change
- Transport Package：Plywood Case Package
- Specification：Working Area: 1300*2500*200mm
- Trademark：Mars
- Origin：China
- HS Code：8465990000
- Production Capacity：3000 Sets,Year
Description
OthersTool Magazine Carrousel, 8pcs Lubrication System Automatic Transmission XY axis rack and pinion PMI, Z axis ball screw TBI Guide Rail Taiwan PMI/Hiwin 25mm rectangular linear rail Inverter Zoncn/Delta 11KW Positioning cylinder 5pcs Tool sensor MARS Limit switch Japan Omron Vacuum Pump 1*7.5KW water vacuum pump Cable MARS cable, anti-static, anti-interference, bending resistance Beam Reinforced steel beam Max Travelling Speed 50m/min Max Processing Speed 30m/min Working Accuracy ±0.02mm Re-positioning Accuracy ±0.05mm Dictate Format G-Code / HPGL Working Voltage AC380V/ 3PH/ 50HZ Support Software Professional cutting optimization software(JiFusen/Yunxi/Tomder/Haisense) Net Weight 1800KG
Performance Features:4. Performance Feature1 Equipped with all the leading international brand components, Taiwan Syntec control system, Japan Yaskawa servo motor and driver 2 Carousel type tool magazines support automatic tool changer, improve processing efficiency 3 HSD 9KW high-power air-cooling spindle can withstand high-speed, heavy loading, low noise characteristics 4 Machine body structure is made of welded thick-walled square steel tube, with five-sided tempering, to ensure the body never deformation 5 Vacuum table, high adsorption capacity, able to adsorb materials of different sizes 6 Taiwan-made guide rail and ball screw, high precision, long service life, good stability 7 Taiwan Syntec control system, easy to operation,fully support automatic production 8 Taiwan planetary reducer, with small volume, large torque, high transmission efficiency, wide range of deceleration 9 Intelligent protection work table can prevent table damages caused by misuse or software errors. Intelligent processing cross-border protection can prevent mechanical collisions while design layout exceeds processing area
