4X8FT Hydraulic Hot Press Machine for Plywood Production Line

Linyi Sin San Lin Smart Machinery Co., Ltd.
  • Work Forms：Hydraulic Pressure
  • Processing Technics：Hot Press
  • Structure：Frame Type
  • Pressing Shape：Flat Press
  • Platen Surface Pressure：Low Pressure
  • Pressing Layer：Multi Layer

Base Info

  • Model NO.：BY214X8,5-12IIZ
  • Work Mode：Period
  • Controlling Mode：CNC
  • Automatic Grade：Automatic
  • Certification：CE, ISO
  • Voltage：380V,415V,440V
  • Heating Medium：Hot Steam or Thermal Oil
  • Transport Package：Standard Export Packing
  • Specification：3590*1370*4570mm
  • Trademark：METRO
  • Origin：China
  • HS Code：8465990000
  • Production Capacity：700sets,Year

Description

PressureHot Platen sizeCylindersUnit pressureOpeningNumber of openings400Ton2700x1370x42mm2xφ320mm12kgf/cm260~100mm5~20 500Ton2700x1370x52mm2xφ360mm18kgf/cm260~100mm5~20 600Ton2700x1370x52mm2xφ400mm20kgf/cm260~100mm5~20 800Ton2700x1370x52mm4xφ320mm24kgf/cm260~100mm5~20


4X8FT Hydraulic Hot Press Machine for Plywood Production Line
4X8FT Hydraulic Hot Press Machine for Plywood Production Line
4X8FT Hydraulic Hot Press Machine for Plywood Production Line




How to pack and ship?
1. Machine body packed in plastic film
2. Spare parts and electrical parts packed in plywood boxes.
3. Fixed in container with steel wires.

Our Services?
1. Design and produce based upon your production need. Provide full sets of drawings and manuals.
2. One year warranty for the machine. Liftetime after-sales service and maintenance.
3. Professional team for oversea machine installation&debugging.
4. Help train and guide machine operating.
