Automatic Woodworking PVC Edge Banding Machine for Furnitures

Qingdao Zhongding Machinery Co., Ltd.
  • Warranty：1 Year
  • Function：Gluing, Edge Banding, End Trimming, Fine Trimming, Scraping, Buffing
  • Type：Straight Line
  • Edging thickness：0.4-3mm
  • Automatic Grade：Automatic
  • Panel Feeding Speed：13m,min

Base Info

  • Model NO.：ZD500
  • Certification：CE, ISO
  • Panel Thinkness：10-60mm
  • Min.length panel：100mm
  • Min.width panel：50mm
  • Manufacturing Principles：Glue Tank Underneath
  • Customized：Customized
  • After-sales Service：Video Technical Support
  • Transport Package：Wooden Case
  • Specification：3600*900*1500mm
  • Trademark：ZHONGDING
  • Origin：China
  • HS Code：84659400
  • Production Capacity：500 Sets,Month

Description

ModelZD500Banding tape thickness0.4-3mmBanding tape width10-60mmWorkpiece thickness10-60mmWorkpiece length>=100mmWorkpiece width>=50mmHeating power1.5kwFeeding motor power2.2kwGlue spreading motor power0.37kwEnd trimming motor power0.55kw*2Fine trimming motor power0.75kw*2Polishing motor power0.18kw*2Feeding speed13m/minAir pressure0.7MpaTotal power6.23kwOverall dimension3600*900*1500mmPacking size36700*1000*1600mmN.W.1300KGS

Highlight of edge banding machine

  • Nover construction
  • stable performance
  • easy operation
  • frequency converter for different kinds of banding material
