Economical Circle CNC Router Engraing Cutting Machine for Wood Furniture Cabinets

Jinan Chanke Mechanical Equipment Co., Ltd.
  • Type:Engraving Router
  • Spindle Layout:Spindle Over
  • Spindle Number:Single-Spindle
  • Feed Mode:Mechanical
  • Controlling Mode:CNC
  • Certification:CE, ISO, FDA

Base Info

  • Model NO.:CK1325
  • Customized:Customized
  • Condition:New
  • Color:Customized
  • Transport Package:Plywood Packing
  • Specification:3.43CBM
  • Trademark:CHANKE
  • Origin:Shandong
  • HS Code:8456999900
  • Production Capacity:50set Per Month

Description

Basic Info.

Model NO. CK1325 Customized Customized Condition New Color Customized Transport Package Plywood Packing Specification 3.43CBM Trademark CHANKE Origin Shandong HS Code 8456999900 Production Capacity 50set Per Month

Product Description

CK1325 wood cnc router machine can do the engraving and cutting on metal acrylic wood mdf and other metal and nonmetal materials .

working size : 1200x1800/900mm/ 1300x2500mm/ 2000x3000mm/1500x3000mm  or as customer choice , of course the machine colour , customer aslo can send us their machine structure photos and we can according your requirments to help you design the machine .



Machine spindle power separated : 1.5kw/3.5kw/4.5kw/5.5kw/7.5kw water cooling spindle power. if you want to engraving on wood or other materials, choose 1.5kw-4.5kw is ok. if cutting more thickness wood , please choose bigger one .

3.Parameter


BrandCHANKE
ModelCK-1325 wood cnc router
Engraving area
(W*L*thickness)(mm)

1300*2500*200
Working FormFull-automatic
Spindle Power3.0kw/4.5/5.5kw as customers choice
Spindle Rotate(rpm)6000~24000mm/min
Motor  stepper motor or Servo motor imported from Japan as your choice
Tool Diameter(mm)Ø3.175,Ø4,Ø6/8mm, Ø12.7mm
Machine StructureThicker Welded Steel tube Structure for 8mm thickness
Transmission System

X,Y Axis: Helical Rack and Pinion Drive
Z Axis: Taiwan TBI ball Screw

X,Y,Z RailTaiwan HIWIN square rail
X,Y,Z Traveling Positioning Accuracy±0.03/300mm
Engraving Speed(mm/min)8000~12000mm/min
Feeding Speedmanual
Data TransmissionUSB or PC connect
Support FormatG code or HPGL
Working VoltageAC220V/50Hz or 380V/50Hz
software  CAD/CAM,Artcam,Castmate,Ug,Wentai,Type3.  UCancamV8
Range of ApplicationWoodworking relief engrave ,Cutting , Hollow
Machine Net Weight1680Kg

 Applicable materials

1) Furniture: plate, office furniture, doors, cabinets.

2) Wood products: speakers, games cabinets, computer tables, sewing machines,  musical instruments.

3) Board processing: insulation, plastic chemical components, PCB, car body,

bowling track, ABS, PP, PE, etc.

4) Decoration: Acrylic, PVC, MDF, glass, plastic and soft metals such as copper  and aluminum.

8. Guarantee & service of Machine



Two years quality guaranty, the machine with main parts(excluding the

consumables) shall be changed free of charge when if any problem during the

warranty period.

Service: ( Provide whole life technical support, 24h online )

Before sale:

We would always be here to provide any information you need at the first time,

and give professional suggestions according to your real needs for free;

During sale:

We would deal with all the production and shipping affairs, after everything is

ready, we would tell you everything goes well here;

After sale:

1) We would provide English Version working manual.

2) If you have any questions during using and maintaining, our engineers who

could speak very good English would answer you online or by calls.

3) Machine warranty is one year. So if your machine has any unintentional

damages, we would provide parts for free.

4) If your machine has big problems if by any chance, our engineers would arrive

 there to debug and fix.

5) Could be remote control if needed.
