• Model NO.：R-S1,R-S2
• Specification：RMZ73211
• Trademark：SAMACH
• Origin：China
• HS Code：84659500
• Production Capacity：80sets,Month

Basic Info.

Model NO. R-S1/R-S2 Specification RMZ73211 Trademark SAMACH Origin China HS Code 84659500 Production Capacity 80sets/Month

Product Description

Bore and dowel machine R-S1/R-S2



Function introductions
This is made for the automatic board side processing machining center, integrated side drilling, milling slot, doweling (auxiliary automatic glue), it supports the processing of bar code scanning import and manual import

1 Dowels automatic indentation
Precision wood glue into the pressure, to ensure that the pin fastening; high-speed nail into the shock plate for rapid feeding, free waiting; auxiliary silo automatic feeding, to solve the frequent artificial feeding troubles


One click glue gun cleaner
One click, easy to achieve the glue gun move to the designated location of automatic cleaning.


Multi-work processing
According to the length of the plate, up to four processing areas can be independently processed to reduce processing waiting


Reliable positioning precision
There's 3 stop device at the left,middle,right of X-axis direction,Y axis direction positioning wheel and correlation fiber positioning,clamping cylinder press in the Z-axis direction.


Processing file is loaded by code scanned
Through the scanning gun to load the file quickly, sEerial communication to ensure reliable and efficient data transmission


Easy to edit processing documents
Processing documents using plain text numerical editing, simple and easy to operate.


Security
Emergency Stop Switch,pull switch,threshold switch.

Parameters

Model	R-S1/R-S2
Spindle power	1.5KW
Spindle RPM	0--24000r/m,adjusted by VFD knob control
Speeds &stroke for X	40M/min&2440 mm
Speeds &stroke for Y	10M/min&80 mm
Speeds &stroke for Z	10M/min&50 mm
Capacity of bore and insertion	60 insert/min
Max drilling depth	50mm
Maximum dowel insertion depth	40mm
Packing size	3462*1133*2015mm
Weight	1615Kg

Reasons to choose Samac:

1: good resources with No.1 quality in China
2: quick delivery
3: excellent after-sale services
4: 24 hours technical support through email or calls.
5: freind partner relationship.

Get the maximum return on your investment with Samach's affordable, flexible and user-friendly machines, designed to help you succeed by delivering maximum performance!
