• Model NO.：1325
• Customized：Customized
• Condition：New
• Color：Customized
• Drive Mode：Stepper
• Control System：Nc Studio
• Guild Rail：Hiwin Square Rail
• Ball Screw：PMI, Taiwan
• Transport Package：Standard Exported Plywood Case
• Specification：SGS
• Trademark：DONGTONG
• Origin：Jinan China
• HS Code：84609090
• Production Capacity：50 Sets Per Month

Basic Info.

Model NO. 1325 Customized Customized Condition New Color Customized Drive Mode Stepper Control System Nc Studio Guild Rail Hiwin Square Rail Ball Screw PMI, Taiwan Transport Package Standard Exported Plywood Case Specification SGS Trademark DONGTONG Origin Jinan China HS Code 84609090 Production Capacity 50 Sets Per Month

Product Description

1325 Advertising Cnc Router, Woodworking CNC Engraving Machine
from professional cnc router manufacturer




1. The table is made by whole and thick-walled steel pipe;
2. Through finite element analysis (FEA) analysis and design, make the machine stability and  high precision.
3. Rolling ball screw from Taiwan, original screw nut, imported linear and square rail.
4. Gantry movement for heavy products.
5. Control system: PCI system, 3D display and following.
6. Software compatibility: Wentai, carved, Tyie3, Artcam, Ucancam8, CAXA and other CAD/CAM software.
7. Re-carving after stopping and the power failure may be restored.
8.Processing time prediction






Model	1325
Working area	1300×2500×200
Spindle power	3Kw water-cooling
Running speed	30000mm/min
Spindle rotational speed	0-24000r/min
Cutting tool diameter	6mm/12.7mm
Software support	HPGL or G Code
Working precision	±0.02mm
Remark	The above is common one, all specification can be customized.
Optional	1. Servo system     2. Dust collection       3. Vacuum table
Important parts:	1. Ball screw and Liner rail:  Imported from Japan and Taiwan; 2.  Spindle motor: High quality domestic water-cooling spindle.

Technical support:
1. Technical support by phone, email or MSN/ Skype around the clock
2. Friendly English version manual.
3. Engineer available to service machinery overseas. but the buyer should pay the fee.

After-sale & guarantee service:
1. Under normal usage, 1 year for the whole machine and 6 months for spindle
2. Normal machine is properly adjusted before dispatch.
3. You will be able to get free training advice towards our machine in our factory.
4. You will also get free suggestion and consulting, technical support and service by email/fax/ tel and
     lifetime technical support


1325 advertising and woodworking cnc router, Customizaiton is available.
