Multi Process Engraving Machine Woodworking CNC Router for Wood, Acrylic, MDF, PVC
Jinan Guanjiahong CNC Machinery Co., Ltd.- Condition：New
- Certification：CE, SGS
- Application：Wood, MDF, Arylic
- Guide Rail：Hiwin 25
- Screw：Tbi 2510
- Running Mode：Servo
Base Info
- Model NO.：GJH 1325-3
- Driver：Delta (Optional Yaskawa)
- Motor：750W
- Spindle：6kw & 4.5kw, Air Cooling
- Control System：Nc Studio 95A
- Transport Package：Plywood Case
- Specification：GJH1325-3
- Trademark：GJH
- Origin：Shandong China
- HS Code：84659900
- Production Capacity：50 Sets Per Month
Description
Basic Info.
Model NO. GJH 1325-3 Driver Delta (Optional Yaskawa) Motor 750W Spindle 6kw & 4.5kw, Air Cooling Control System Nc Studio 95A Transport Package Plywood Case Specification GJH1325-3 Trademark GJH Origin Shandong China HS Code 84659900 Production Capacity 50 Sets Per MonthProduct Description
1. Asynchronous multi-head woodworking CNC Router Machine is customized for changing the tools within 3 pieces. It's not only economic, also can realize auto tool change, save the time of manual tool change and improve the working speed and precision.
2. Three spindles can use three different toolsfor three different processing at the same time, which is similar with an economical auto-tool changer cnc machine center with three tools.
3. Vacuum table with absorption/suction blockto assist the side drilling and milling process.
4. Whole machine is welded with seamless steel structure, which is high temperature annealing and vibrating stress relief, so the lathe body is stabilized and will not be deformed forever.
5. Table is equipped with alignment pop-up pinsfor you to fix the work piece quickly.
It is widely used for production of cabinet door, solid wooden door, computer desk, assembling furniture and large area and mass engraving on MDF and HDF, wood board, plane cutting, 3D embossment, etc.
| NO | Index | Index | Parameter |
| 1 | Traveling | X axis | 1300mm |
| Y axis | 2500mm | ||
| Z axis | 180mm | ||
| 2 | Table size | 1300x2500mm | |
| 3 | Accuracy | Working accuracy | 0.02mm |
| Reposition accuracy | 0.02mm | ||
| 4 | Transmission | X axis | Rack |
| Y axis | Rack & Double moters | ||
| Z axis | Screw | ||
| 5 | Speed | Max Rapid | 25000mm/min |
| Max working speed | 15000mm/min | ||
| 6 | Spindle | Spindle power | 6KWx1Pc; 4.5KWx2pcs |
| (Water-cooling) | Spindle speed | 0-18000r/min | |
| 7 | Drive mode | Stepper | |
| 8 | Working voltage | AC380/50HZ | |
| 9 | Command language | G Code | |
| 10 | Operation system | Nc Studio 95A-3L |
If you have any specific requirements for woodworking CNC router, customization is available.
