Woodworking Machinery

Heavy Model Fine Cast Veneer Peeling Machine

Linyi Sin San Lin Smart Machinery Co., Ltd.
  • Certification:CE, ISO
  • Power:29kw
  • Max. Peeling Diameter:φ380mm
  • Transport Package:Stand
  • Specification:Cast Iron Body
  • Trademark:METRO MACH

Base Info

  • Origin:Shandong, China
  • Production Capacity:55m,Min

Description

Basic Info.

Origin Shandong, China Production Capacity 55m/Min

Product Description

Heavy Model Fine Cast Veneer Peeling Machine


The thickness of peeling veneer can adjust  from 0.5mm to  3.6 mm
The diameter of remaining wood core is less than 30 mm
English language PLC is easy to operate
Bigger power invert
Best Cast steel body
  Heavy Model Fine Cast Veneer Peeling Machine
ModelMQS1813/300MQS1813/380MQS1813/380S
GradeAAAAAA
Max. working length1400mm1400mm1400mm
Max .diameter φ300mmφ380mmφ380mm
Diameter of Left woodφ30mmφ32mmφ32mm
Working speed range45m/min50m/min55m/min
Thickness of veneer0.5-3mm0.5-3.2mm0.5-3.6mm
Main motor power2X11kw China motor2X11kw China motor2X15kw China motor
Servo motor Power7kw CTB servo China7kw Mitsubishi Japan11kw Mitsubishi Japan
BodyCast steel bodyFine cast steel bodyFine cast steel body
Automatic hydraulic knife clamping systemN/normal mechanical change knifeN/automatic hydraulic optionsAutomatic hydraulic 4kw change knife
Double roller driverBy gearBy gearBy gear
Total power29kw29kw45kw
Machine weight4100kg4900kgs5500kgs







Heavy Model Fine Cast Veneer Peeling Machine






Pre-sale services:
1) Provide the free consultation of the equipment
2) Provide the standard device and the flow chart
3) According to the clients' special requirement, offering the reasonable plan and free design to help to select the equipment.
4) Welcome to visit our factory

Services during the sales:
1) Inspect the machine before leaving the factory.
2) Oversea install and debug the equipment
3) Train the first-line operator.

After sale services:
1) 24 hours online service
2) Provide the video  with Install and debug the equipment
3) Provide technical exchanging
