Three Heads Heavy Duty Wide Belt Calibrate Polishing Sander Machine
Linyi Sin San Lin Smart Machinery Co., Ltd.- Type:Belt Wood Sander
- Automatic Grade:Automatic
- Variable Speed:Variable Speed
- Certification:CE, ISO, FDA
- Customized:Customized
- Condition:New
Base Info
- Model NO.:BSG1313R-R-P
- Color:Customized
- Working Application:Plywood,Blockboard,Particleboard
- Working Voltage:380V,415V,440V and So on
- Transport Package:Container
- Specification:3150*2900*2440mm
- Trademark:METROMACH
- Origin:China
- HS Code:8465930000
- Production Capacity:500sets,Year
Description
Basic Info.
Model NO. BSG1313R-R-P Color Customized Working Application Plywood/Blockboard/Particleboard Working Voltage 380V/415V/440V and So on Transport Package Container Specification 3150*2900*2440mm Trademark METROMACH Origin China HS Code 8465930000 Production Capacity 500sets/YearProduct Description
Product Description:Heavy Duty Three Heads Wide belt Calibrate Polishing Sander Machine1. Main features:This machine is suitable for the thickness setting, light sanding and fine polishing of the small
type wood board, veneer, chipboard, fiberboard, middle dense board, aminatedboard, and variety
of sheet materiaks for the funiture factory and the board mill.
The roller's diameter is much bigger and the rollers have been run-balanced precisely, which makes running smoothly and improves the sanding power.
2. Technical parameters:
Model. No | BSG1313R-R-P |
1.Sanding width | 40-1300mm |
2.Sanding thickness | 2.5-80mm |
3.Size of sanding belt | 1330*2800mm |
4.Voltage | 380V 50Hz |
5.The first head | Motor 75kwφ294mm steel roller |
6.The second head | Motor 55kwφ400mm robber roller |
7.The third head | Motor 22kw hard polish pad |
7.Transport reducer | 7.5kw |
8.Transoprt speed | 20-40m/min |
9.Lifting motor | 0.75kw |
10.brushing motor | 0.75kw |
11.Total motor | 154kw |
12.Operating pressure | 0.6MPa |
13.Dust extraction | 15000m³/h |
14.Speed of dust extraction | 25-30m/s |
15.Dimension | 3150*2900*2440mm |
16.Weight | 10500kg |
3. More Pictures
Welcome to Contact
