Woodworking High Quality Wood Veneer 4FT Spindle Less Peeling Machine

Linyi Sin San Lin Smart Machinery Co., Ltd.
  • Type：Veneer Peeling Machine
  • Automatic：Automatic
  • Certification：CE, ISO, FDA
  • Max Working Length：1400mm
  • Max Log Diameter：500mm
  • Transport Package：Container

Base Info

  • Model NO.：SP1400-II
  • Specification：3600*1900*1400mm
  • Trademark：METROMACH
  • Origin：China
  • HS Code：8465960000
  • Production Capacity：10set,Month

Description

Basic Info.

Model NO. SP1400-II Specification 3600*1900*1400mm Trademark METROMACH Origin China HS Code 8465960000 Production Capacity 10set/Month

Product Description

Product Description
1. Product Features
Spindleless veneer peeling machine is used for make veneer .
And it is suitable for the eucalyptus, pine, cotton wood and another log.
The quality of the veneer determines the quality of the plywood, so controlling the quality of the veneer is the premise and the most important part of producing standard plywood.
veneer peeling machine is a very technical equipment in plywood line equipment.

2. Technical Parameters

Machine name4'FT NC Spindleless rotary peeling machine
Machine modelB
Max working length1400mm
Max working diameterΦ500mm
Min working diameterΦ33mm
Veneer thickness range0.6-5.0mm
Rotary peeling speed60m/min
Roller diameter125mm
Single roller motor5.5KW
Double roller motor11KW
Feed motor7.5KW
Cutting motor1.5KW
Conveyor1.5KW
Total power27.5KW
Machine weight4000KGS
Machine size3600X1900X1400mm

3. More PicturesWoodworking High Quality Wood Veneer 4FT Spindle Less Peeling Machine



Woodworking High Quality Wood Veneer 4FT Spindle Less Peeling Machine

Woodworking High Quality Wood Veneer 4FT Spindle Less Peeling Machine
