• Model NO.：DW6090
• Customized：Customized
• Condition：New
• Color：Customized
• X,Y Working Area：600mm*900mm
• Z Working Area：100mm
• Processing Precision：0.05mm
• Reposition Precision：0.02mm
• Table Structure：T-Slot Extrusions
• Spindle Power：1.5kw
• X,Y,Z Structure：Ball Screw
• Max Ilding Speed：12000mm,Min
• Operation Command：G Code
• Drive Motor：Stepper
• Transport Package：Plywood Box, Free From Fumigation
• Specification：CE
• Trademark：DWIN
• Origin：Jinan, Shandong, China
• HS Code：846599
• Production Capacity：50sets Per Month

8Y StructureHiwin Rail Linear Bearings and Ball Screw9Max. power Consumption 0.8Kw10Max. Rapid Travel Rate 8000mm/min11Max. Working Speed12000mm/min12Spindle Power Motor1.5Kw self cooling spindle13Spindle Speed0-24000RPM14Drive Motors Stepper system 15Working VoltageAC220V/50/60Hz 16Command Language G code17Operating SystemDSP System (Option:Mach3 PC Software) 18InterfaceUSB19Flash Memory128M(U Disk) 20ColletER1621X,Y Resolution <0.01mm22Software Compatibility Type3 software, Ucancam software, (Option: Artcam software)23Running Environment Temperature: 0°C~45°C Relative humidity: 30%~75%24Packing Size1710 *1250 * 1585mm25Net Weight180KG26Gross Weight272KG
Machine details
Spindle


Working table parts


Samples made by the machine
