CE ISO SGS Approved Biomass Pellet Mill Machine for Sale

Jiangsu Liangyou Zhengda Co., Ltd.
  • Type:Ring Die Wood Pellet Machine
  • Voltage:380V
  • Automatic Grade:Automatic
  • Controlling Mode:CNC
  • Energy Saving:Energy Saving
  • Certification:CE, ISO

Base Info

  • Model NO.:WZLH420
  • Warranty:1 Year
  • Customized:Customized
  • Condition:New
  • Color:Multi Color
  • After-sales Service:Provided
  • Material of The Machinery:Stainless Steel or Carbon Steel
  • Size and Weight:as Per Requirements
  • Motor Brand of Thte Main Pelletizer:Siemens
  • Oil Seal of The Pelletizer:Imported From Germany
  • Bearing Brand of The Pelletizer:SKF
  • Transport Package:Iron Pallet
  • Specification:1500KG
  • Trademark:FDSP
  • Origin:Jiangsu China
  • HS Code:8479300000
  • Production Capacity:0.8-1.2t,H

Description

Basic Info.

Model NO. WZLH420 Warranty 1 Year Customized Customized Condition New Color Multi Color After-sales Service Provided Material of The Machinery Stainless Steel or Carbon Steel Size and Weight as Per Requirements Motor Brand of Thte Main Pelletizer Siemens Oil Seal of The Pelletizer Imported From Germany Bearing Brand of The Pelletizer SKF Transport Package Iron Pallet Specification 1500KG Trademark FDSP Origin Jiangsu China HS Code 8479300000 Production Capacity 0.8-1.2t/H

Product Description

CE ISO SGS Approved Biomass Pellet Mill Machine For Sale
CE ISO SGS Approved Biomass Pellet Mill Machine for Sale
CE ISO SGS Approved Biomass Pellet Mill Machine for Sale
CE ISO SGS Approved Biomass Pellet Mill Machine for Sale
CE ISO SGS Approved Biomass Pellet Mill Machine for SaleCE ISO SGS Approved Biomass Pellet Mill Machine for Sale
More Models for Choosing as below:
ModelWZLH420WZLH508WZLH680
Ring die inner diameter (mm)420500688
Ring die working width(mm)90100110
Ring die linear speed (m/s)3.163.783.54
Number of clamp3 pcs3 pcs8 pcs
Number of roller2 pcs2 pcs2 pcs
Number of cutter1 pcs1 pcs1 pcs
Motor power90+2.2+0.7590+2.2+1.5185+3.0+1.5
Motor rotation speed750750595
Ring die hole   diameter(mm)6/8/106/8/106/8/10

Applications of Wood Pellet Production Line
It is mainly used for agro-forestry residues ,such as straw ,cotton stalk , rice husk ,peanut shell ,bamboo,empty fruit branch,pulverized coal and waste paper etc.
CE ISO SGS Approved Biomass Pellet Mill Machine for Sale

The main features of complete wood pellet production line

1. The main drive of our complete wood pellet production line adopts the high accuracy gear driving, so the output is 20% more than the belt drive.It makes gear directly-connecting as the driver, and is with quick-release die fixed by clamps, which can increase the output 15% more than the same type machine with belt-convey.

2. It uses the imported bearing and oil seal to make sure the high-efficiency, stable performance and low noisy of the whole machine.

3. The pelletizing chamber is equipped with air suction cooling system.

4. The feeder of our complete wood pellet production line uses variable-frequency and variable-speed motor to make sure the good quality of the pellet.

5. Advanced world standard compensatory S-shaped coupling with the structure of novel, compact, safe, low-noisy and low fault.

6. Feeder, conditioner and chute of our complete wood pellet production line made of stainless steel with long service life.

7. Our complete wood pellet production line with magnet and over load protection system, which can protect machine well during production

8. We have different bore diameter of the ring dies for your choice. And the feeder is with a variable speed controlled to meet different outputs requirements.
