• Model NO.：FM1325
• Customized：Customized
• Condition：New
• Color：Customized
• Control System：DSP,Nc-Studio,Mach3
• Engraving Area：1300*2500*200
• Spindle Power：3.0kw Water Cooling Spindle
• Motor Type：Stepper,Servo
• Guide Rail：Taiwan Hiwin Square Linear Rail
• Working Speed：8-15m ,Min
• Software：Artcam, , Type3
• Table Structure：Vacuum and T-Slot Table
• Inverter：Best , Fulong , Delta
• Transmission Way：Rack Gear
• Transport Package：Wooden Box
• Specification：CE ISO SGS
• Trademark：FIRMCNC
• Origin：Jinan Shandong China
• HS Code：8456100090
• Production Capacity：5000 Sets,Year

Basic Info.

Model NO. FM1325 Customized Customized Condition New Color Customized Control System DSP/Nc-Studio/Mach3 Engraving Area 1300*2500*200 Spindle Power 3.0kw Water Cooling Spindle Motor Type Stepper/Servo Guide Rail Taiwan Hiwin Square Linear Rail Working Speed 8-15m /Min Software Artcam, / Type3 Table Structure Vacuum and T-Slot Table Inverter Best / Fulong / Delta Transmission Way Rack Gear Transport Package Wooden Box Specification CE ISO SGS Trademark FIRMCNC Origin Jinan Shandong China HS Code 8456100090 Production Capacity 5000 Sets/Year

Product Description

Woodworking Furniture CNC Router 1325 cnc wood router

1. This machine is from Jinan Firm CNC Equipment Co., Ltd. It is a type of woodworking machine, which is equipped with aluminium profile table. It has the T-solt, using the material holders to fasten the mould on the table. There are many occasions it can work: Cutting or engraving on the MDF, soild wooden door, computer desk, cupboard door and window, bedside cabinet, furniture decoration, , wood board, acrylic and so on.

2. As for the spindle, we have the 3.0KW Chinese water cooling spindle and the HSD air cooling spindle; For the motor, we have leadshine stepper motor and Servo motor, you can choose from them as you requirements. The machine adopt the Fuling inverter, which can ensure the high speed and high precision, and can realize milling with low noise. About the rail, it adopt the world famous rail and guide manufacturer Taiwan Hiwin squre rails, self-lubricating sliding block, no need of human, very convenience. The XY axises adopt gear transmission, Z axis adopt Taiwan ball screw transmission.
We also have vacuum table wood CNC router, 3 pieces of head wood CNC router, ...If any of them interest you, please tell me rapidly.



3. Applications:
It is widely used in the Small-scale woodworking industry, such as solid wood door engraving, MDF paint door carving, furniture processing.
In artwork industry, it can process wooden craft, musical instrument.
It can also used in the decorative doors and windows processing etc.

Technical specification

Brand	Firm
Model	FM-1325
Machine Size (mm)(W*L*thickness)	1900*3100*1800
Table size(mm)	1600*3100
Engraving area (W*L*thickness)(mm)	1300*2500*200
Working Form	Full-automatic
Spindle Power	3.0KW water cooling spindle
Spindle Rotate(rpm)	6000~24000
Motor Driver	Stepper motor (Chinese servo motor or imported servo motor is optional)
Tool Diameter(mm)	Ø3.175,Ø4,Ø6, Ø12.7mm
Machine Structure	Industry square tube structure
Transmission System	Imported ball screw or high accuracy gear rack
X,Y,Z Rail	Imported square rail
Mechanical Accuracy	<0.03/300mm
Engraving Speed(mm/min)	8000~12000mm/min
Feeding Speed	manual
Data Transmission	PC connect
Support Format	G code or HPGL
Working Voltage	AC220V/50Hz or 380V/50Hz
Support Format	G Code or HPGL
Range of Application	Woodworking relief engrave ,Cutting , Hollow
Machine Net Weight	1200Kg

Company Information
Jinan Firm CNC Equipment Co., Ltd is situated in Jinan city, Shandong province. We are a professional and good reputation manufacturer of CNC router, laser engraving machine, CNC plasma cutter, laser cutting machine, laser marking machine in China to the new and existing customers that are spread throughout the South America, Middle East, Southeast Asia, Africa, Europe and other counties of the world and the machines has passed the EU CE certificate.


Our Services
1) The whole machine guarantee is 12 months except for special parts.
2) 24 hours technical support by phone, email or MSN, skype etc.
Our QC team
A QC team with professional and technical personnel. To ensure 100% products checking.
Material: Strictly control of material using, meet international requested standards.
Semi-finished products inspection: Product inspection before 100% finished.
Production line test: With work team or data engineer who will inspect machines and lines at fixed period.
Finished Product Inspection: Quality and property test before products are packed and loaded.

Packaging & Shipping
Water-proof plastic film package with foam protection in each corner.
Solid Seaworthy Wood Box Package with Steel Belt.
Save space as much as possible for container loading.

FAQ
1. How long is the delivery time of antique furniture CNC router?
For standard machines, it would be 7-10 days; For non-standard machines and customized machines according to client s specific requirements, it would be 15 to 30 days.
2. How about the payment terms of antique furniture CNC router?
30% T/T for deposit, 70%T/T paid before shipping.
T/T, West Union, Paypal
3. Do You Arrange Shipment For The Machines of antique furniture CNC router?
Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you. For EXW price, clients need to arrange shipment by themselves or their agents.
4. How about Guarantee & After Sales Service of antique furniture CNC router?
The machine guarantee is 12 months. 2) 24 hours technical support by phone, email or MSN, skype etc.
