• Model NO.：FM6090
• Customized：Customized
• Condition：New
• Color：Customized
• Working Area：600*900mm
• Z Structure：Ball Screw
• Max. Consume Power：3.0kw
• Interface：USB
• X,Y Working Delicacy：<0.01mm
• Transport Package：Wooden Box
• Specification：CE SGS ISO
• Trademark：FIRMCNC
• Origin：Jinan Shandong China
• HS Code：8465990000
• Production Capacity：300S,M

Basic Info.

Model NO. FM6090 Customized Customized Condition New Color Customized Working Area 600*900mm Z Structure Ball Screw Max. Consume Power 3.0kw Interface USB X,Y Working Delicacy <0.01mm Transport Package Wooden Box Specification CE SGS ISO Trademark FIRMCNC Origin Jinan Shandong China HS Code 8465990000 Production Capacity 300S/M

Product Description

High Quality Advertising Woodworking Mini CNC Router

This kind of machine is the main products of Jinan Firm CNC Equipment co, . Ltd which specialize in the produce of the machine. The machine can precess and make the including woody products, sign products, bill plates, chest brands, seals, metal foil moulds, constrction models, instrument panel and industrial moulds or non-metal materials, for example, iron, copper, aluminum, plastic plates, wood plate, etc.


Features
1. The Lathe bed is one-piece cast Iron and will never warp.
2. Two-motor drive system ensures quick, even, stable operation
3. The vacuum cleaning system offers a clean working environment and better quality
4. High performance Subdivision stepper motor operates smoothly at maximum speed.
5. Highly accurate gears allow for engraving characters as small as 1.5mm
6. The unique calculating system realizes speedy, accurate, curvy operation
7. Large Water-cooled High-Frequency High-Power Motor features low noise, constant speed, and long operational life
8.12 Month Warranty on parts and Labour
Performance features:
9. Integral cast iron frame, more durability.
10. Inported all steel linear guide with high precision, ensure machine frame much stability and dutability.
11. High accuracy rolling ball screw from Gemany, assure machine frame of better precision.
12. Handle controlling, not occupying computer resource, one computer can control several equipments.
13. Be compatible with various CAD/CAM software as TYPE3/Artcam/Casmate/Artcut etc.


Technical specification

NO.	Description	Parameter
1	X,Y,Z Working Area	600x900x100mm
3	X,Y,Z Traveling Positioning Accuracy	±0.03/300mm
4	X,Y,Z repositioning Positioning Accuracy	±0.05mm
5	Lathe Structure	Cast Aluminum
6	X, Y Structure	Shaft Linear Bearings and Ball Screw
7	Z Structure	Ball Screw
8	Max. Consume power	3.0Kw
9	Max. Speed	0-5500mm/min
10	Max. Working Speed	0-3000mm/min
11	Spindle Power Motor	1.5kw water-coolant spindle
12	Spindle Speed	0-24000RPM
13	Drive Mode	Stepper Motor
14	Working Voltage	AC220V/380V, 50/60Hz
15	Command	G code, *uoo, *mmg, *plt
16	Operating System	DSP System
17	Interface	USB
18	Flash Memory	128M
19	Collet	ER11
20	X,Y Working Delicacy	<0.01mm
21	Software	Type3,  Ucancam,  Artcam
22	Running circumstance	Temperature: 0~45 Relative humidity: 30%~75%
23	Packing Size	910X880X800mm
24	Net Weight	100KG
25	Gross Weight	150KG

Samples


Packaging & Shipping
Water-proof plastic film package with foam protection in each corner.
Solid Seaworthy Wood Box Package with Steel Belt.
Save space as much as possible for container loading.

Our Services
# One year warranty for the machine
# Replacing all parts for free during warranty
# If nessessary, provide door to door service to your country
# 24 hours on line service
# Replying your email and offer tecnical service within 24 hours


Company Information
Jinan Firm CNC Equipment Co., Ltd is situated in Jinan city, Shandong province. We are a professional and good reputation manufacturer of CNC router (router cnc, cnc wood router), laser engraving machine, CNC plasma cutter, laser cutting machine, laser marking machine in China to the new and existing customers that are spread throughout the South America, Middle East, Southeast Asia, Africa, Europe and other counties of the world and the machines has passed the EU CE certificate.


FAQ
Question 1: How long about the machine's guarantee?
Answer: 1 year
Question 2: How about your after service?
Answer: Technical support by phone, e-mail or MSN around the clock.
Question 3: How can we install the machine?
Answer: Friendly English version manual and operation video CD disk.
Question 4: How about the payment terms?
Answer: 30% T/T for deposit, 70%T/T paid before shipping.
T/T, West Union, Paypal
