• Model NO.：JS-48
• Color：Customered
• Cutting Thickness：10-60mm
• Transport Package：Nude Packing Inner Container
• Specification：25 cbm after container loading
• Trademark：Yihe machinery
• Origin：China
• Production Capacity：600 Sets Per Year

Basic Info.

Model NO. JS-48 Color Customered Cutting Thickness 10-60mm Transport Package Nude Packing Inner Container Specification 25 cbm after container loading Trademark Yihe machinery Origin China Production Capacity 600 Sets Per Year

Product Description

Machine description:
    This equipment is one of the main equipment for the plywood manufacturers to complete the section. It is mainly used for the saw edge of artificial plates, such as multi-layer board, carpenter board, particleboard, density board and so on. The size of the saw edge is 48ft,adjustable 20mm for a side, the machine speed is high, the size of the timber is standard and unified.

Features:
(1) PLC control system, using 11 sensor switch, motor traction with PLC, biaxial linkage, fast speed, large output, program setting, any two people operation, greatly reduces the labor cost.

(2) The size of the saw edge is 48ft,adjustable 20mm for a side.

(3) Base is welded.Let machine runs smoothly and with high accuracy.circulating lubricating oil have long service life.

(4) 6 saw blades (4 big 2 small), speed up to 6800 rpm, underlined function, fully solve the rendering, burr, burr, core pulling phenomenon, sawing smooth, without polishing.

(5) Infrared positioning, automatic platoon, load track saw edge, four cylinder positioning, high edge straightness, no corner phenomenon.

(6) Automatic lifting platform, automatic stacking. The installation of lifting platen limiting device has completely solved the problem of uneven packing.
