Woodworking Machinery

Home > Product > Woodworking Engraving Machine

1325 CNC Router Engraver Milling Machine, CNC Wood Engraving Machine for Wood Carving

Jinan Blue Elephant CNC Machinery Co., Ltd.
  • Condition：New
  • Certification：ISO, CE, SGS BV TUV
  • CNC or Not：CNC
  • Voltage：AC380V,50,60Hz, 3pH (Option: 220V)
  • Dimension(L*W*H)：1300X2500X300mm (Optional)
  • Spindle Power：6kw Hqd Air Cooling Spindle

Base Info

  • Model NO.：ELE 1325
  • Spindle Rotation Speed：0-24000rpm
  • Drive Motors：FL118 Stepper Motor with 860h Stepper Driver, 4 S
  • Controlling System：Mach3 for 4axis Control System, with The Wireless
  • Inverter：7.5kw Fuling Inverter
  • Software：Type3, Artcam, Ucancam
  • Table Surface：Vacuum and T-Slot Working Table
  • Type：Engraving Router
  • Spindle Layout：Spindle Over
  • Transport Package：Standard Export Wooden Case
  • Specification：CE, ISO, SGS
  • Trademark：BLUE ELEPHANT
  • Origin：Shandong, China
  • Production Capacity：200 Sets Per Month

Description

DescriptionParameterSpindle

6KW HQD air cooling spindle

Effective Working area1300x2500x300mm (optional)X, Y Structure

PMI #20 linear square guide way for X,Y,Z axis

Z StructureTaiwan TBI ball screw for Z travelMotor and drive

FL118 stepper motor with 860H stepper  driver, 4 sets

Control system

Mach3 for 4axis control system, with the wireless

Inverter

7.5kw Fuling inverter

Rotary device

FL118 and Yako 2811 one set for the rotary device

300mm rotary device

Vacuum pump

5.5KW double stages vacuum pump

StructureHeavy duty body, 10-15mm industrial class square tube strong structureDust collector

1.5KW newest dust collector

Dust covernew model double bags dust collectorTable surfaceT-slot and vacuum table combinedCommand LanguageG Code

PS:All the working area and specifications can be customized according to your requests.

PS: All the working area and specifications can be customized according to your requests

Application

1. Wood Furniture Industry: Wave Plate, fine pattern, antique furniture, wooden door, screen, craft sash, composite gates, cupboard doors, interior doors, sofa legs, headboards and so on.

2. Advertising Industry: Advertising identification, sigh making, Acrylic engraving and cutting, crystal word making, blaster molding, and other advertising materials derivatives making.

3. Die Industry: A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand, plastic sheeting, PVC pipe, wooden planks and other non-metallic mold.

1325 CNC Router Engraver Milling Machine, CNC Wood Engraving Machine for Wood Carving

Packaging Details:

1. Outside package: Standard marine export plywood case.

2. Inner package: Three layers in total; EPE pearl cotton film+PE stretchy film.

Improved package, much more strong and environmental protection.

We can also make package according to your requests.



Delivery Detail: Shipped in 20-30 working days after payment.

1325 CNC Router Engraver Milling Machine, CNC Wood Engraving Machine for Wood Carving

Guarantee and After-sale service:

1. 12 months warranty for the whole machine.

2. Technical support by phone, email or WhatsApp/Skype around the clock.

3. Friendly English version manual and operation video CD disk.

4. Engineer available to service machinery overseas.

BLUE ELEPHANT



1325 CNC Router Engraver Milling Machine, CNC Wood Engraving Machine for Wood Carving

Jinan Blue Elephant CNC Machinery Co., Ltd is located in Jinan City , Shandong Province .

We have always been developing to the research and manufacturer of CNC router machine, plasma cutter, laser cutting engraving machine, which have passed CE, SGS, TUV etc certification.





Welcome to visit us, click https://blueelephant-cnc.en.made-in-china.com to learn more about us.

1325 CNC Router Engraver Milling Machine, CNC Wood Engraving Machine for Wood Carving
