• Production Capacity：37 Kw

Basic Info.

Production Capacity 37 Kw

Product Description



Instructions:

This machine is the ideal equipment for sizing the plywood, compared to the manual model saw, it is more precision,higher efficiency, energy-saving,labor-saving.Adopt the numerical intelligent design, the saw blades can automatically change rotary speed according to the working condition,will not be stopped by resistance,can meet the automatic stacking and saw waste removing.



Main features:

1.The main body is welded by national standard no.1 steel plate,very long working life without deformation.

2.The operating system is accurately controlled by PLC,can save much labors.

3.Main electric parts adopt imported brands, can be used for long time.

4.Adopt the high precision wear-resisting guide rail and infrared positioning device,high sizing precision, the diagonal error is less than 0.3mm.

5.Adopt the pre-loading device, only need two workers,one working shift can produce 3000pcs plywood(10mm  8 hours).

6.Equipped with saw waste collector can remove the saw waste automatically.

7.Special saw dust remover device can keep the working environment clean.



working size:	1830-2500mm X 950-1300mm
Working thickness	10-60mm
Saw edge diameter	φ305
Rip Saws feeding speed	30-60(m/min)
transverse Saw feeding speed	30-60(m/min)
Blade speed	90-120 (m/s)
Total power	37kw
System	Beijing KND absolute coordinate servo system
dimension	6X4.4X1.6m
Weight	5.8T
Capacity	3000pcs/day(8 hours)






Pre-sale Service:
1) Provide the free consultation of the equipment
2) Provide the standard device and the flow chart
3) According to the clients' special requirement, offering the reasonable plan and free design to help to select the equipment.
4) Welcome to visit our factory

Services during the sales:
1) Inspect the machine before leaving the factory.
2) Oversea install and debug the equipment
3) Train the first-line operator.

After Sale Service:
1) 24 hours online service
2) Provide the video  with Install and debug the equipment
3) Provide technical exchanging
